Page 1: Installation Manual
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter INSTALLATION MANUAL SUBMERSIBLE PRESSURE SENSORS 300 SERIES ENTER MENU TVL Series Chemical Resistant Industrial Level Sensors + Displays... -
Page 2: General Information
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter 1. GENERAL INFORMATION 1.1 Information on the operating manual This operating manual contains important information on proper usage of the device. Read this operating manual carefully before installing and starting up the pressure measuring device. Adhere to the safety notes and operating instructions which are given in the operating manual. -
Page 3: Package Contents
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter Permissible media are liquids (no solids or frozen media), specified in the data sheet. In addition it has to be ensured, that this medium is compatible with the any wetted parts of the level sensor. The technical data listed in the current data sheet are engaging and must be complied with. -
Page 4: Installation Steps
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter Do not throw the package | device! To avoid damaging the diaphragm, remove packaging and protective cap directly before starting assembly. The delivered protective cap has to be stored! Place the protective cap on the pressure port again immediately after disassembling. Handle the unprotected diaphragm very carefully - it is very sensitive and may be easily damaged. -
Page 5: Wiring Diagram
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter The default for the Input 1 is 4mA | 0.5V and this will not change. Typically, the Empty setting will be the tank is empty (example. 000.0 Gallons, 000.0 inches, 000.0 feet etc.). 20mA | 4.5V typically reflects the Full setting will be when the tank is full (example: 500.0 Gallons, 120.0 inches, 10.0 feet, etc.) Shielded cable is recommended for control loop wiring. -
Page 6: Electrical Installation
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter 4. ELECTRICAL INSTALLATION WARNING! Install the device only when the unit is not connected! Establish the electrical connection of the device according to the technical data shown on the manufacturing label, the following table and the wiring diagram. Levelpro Wiring Diagram Wiring Diagram 24VDC... -
Page 7: Service & Repair
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter 6. SERVICE | REPAIR 6.1 Return Before every return of your device, whether for recalibration, decalcification, modifications or repair, it has to be cleaned carefully. You have to enclose a notice of return with detailed defect description when sending the device. -
Page 8: Safety Precautions
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter SAFETY PRECAUTIONS About this Manual : PLEASE READ THE ENTIRE MANUAL PRIOR TO INSTALLING OR USING THIS PRODUCT. This manual includes information on all versions of the Levelpro Pressure Level Transmitters Please refer to the part number located on the transmitter label to verify the exact model which you have purchased. - Page 9 Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter How to convert Pressure into Liquid Height? Pressure transmitters are all defined by the pressure range or distance range. To convert pressure to Liquid Height, use the following ratio: 1 psi = 2.31 feet of water 4-20mA | 0.5-4.5V Output 1 psi = 0.704 meters of water...
- Page 10 Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter Levelpro sensors are provided in distance measurement ranges i.e. 0-14 ft, 0-20 ft, 0-33 ft etc. To calculate the maximum range or the liquid that a particular sensor will measure, use the following Maximum Liquid Height (feet) = Maximum Liquid Height of Liquid / SG Example : 0-14 ft transmitter installed in a liquid with a maximum height of 12 feet and a SG=0.9 will...
-
Page 11: Installation
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter INSTALLATION The Levelpro Series is designed to operate while submerged in the actual application liquid. Avoid installing the level transmitter along the bottom of the tank if materials such as sludge will build up and coat/cover the transmitter. This also includes any debris that will settle along the bottom of the tank. -
Page 12: Maintenance
Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter MAINTENANCE After final installation of the Levelpro transmitter and its companion receiver (TruVu), no routine maintenance is required. A periodic check of system calibration is suggested. Be sure to include a brief description of the problem plus any relevant application notes. Contact customer service to receive a return goods authorization number before shipping. - Page 13 Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter WARRANTY, RETURNS & LIMITATIONS Icon Process Controls warrants to the original purchaser of its products that such products will be free from defects in materials and workmanship under normal use and service in accordance with instructions furnished by Icon Process Controls for a period of one year from the date of sale of such products.
- Page 14 Levelpro-Sensors Manual Heavy Duty Industrial Level Transmitter Specification may be modified without notice in advance. For More Information Visit www.iconprocon.com...
