Zanussi ZWD 91683NW User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
GETTING
STARTED?
EASY.
ZWD 91683NW
EN User Manual
Washer Dryer

Advertisement

Table of Contents
loading

Related Manuals for Zanussi ZWD 91683NW

Summary of Contents for Zanussi ZWD 91683NW

  • Page 1 User Manual GETTING STARTED? EASY. ZWD 91683NW EN User Manual Washer Dryer...

  • Page 2: Safety Information

    SAFETY INFORMATION Please be sure to operate the appliance in accordance with the supplied instructions otherwise safety incidents may occur. Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage.
  • Page 3 Connect the mains plug to the mains socket only at the end of • the installation process. Make sure that the mains plug is accessible after installation. The ventilation opening in the base must not be covered by a • carpet, mat, or any floor covering.

  • Page 4: Safety Instructions

    Items such as foam rubber (latex foam), shower caps, • waterproof textiles, and rubber backed articles and clothes, or pillows fitted with foam rubber pads should not be dried in the washer dryer. Fabric softeners, or similar products, should only be used as •...
  • Page 5 • Always use a correctly installed shockproof • Make sure that all metal objects are removed socket. from the laundry. • Do not use multi-plug adapters and extension • Dry only fabrics that are suitable to dry in the cables. appliance.

  • Page 6: Product Description

    PRODUCT DESCRIPTION APPLIANCE OVERVIEW Worktop Detergent dispenser Control panel Door handle Rating plate Drain pump filter Feet for levelling the appliance INSTALLATION ON SUSPENDED FLOORING FIXING PLATE KIT (4055171146) Suspended wooden floors are particularly Available from your authorised dealer. susceptible to vibration. If you install the appliance on a plinth, secure the To limit vibration we recommend placing a appliance in the fixing plates.

  • Page 7: Control Panel

    CONTROL PANEL CONTROL PANEL DESCRIPTION On Off push button (On/Off) Prewash touch button (Prewash) Programme knob Drying level touch button (Drying Level) Spin reduction touch button (Spin) Start/Pause touch button (Start/Pause) Temperature touch button (Temperature) Time Manager touch button Display (TimeAdjust) Drying time touch button (Drying Time)
  • Page 8 C. The time area: G. The spin area: • : the programme duration • : the Spin speed indicator • : the delay start • : the No spin indicator • : the alarm codes • : the Rinse hold indicator •...
  • Page 9 Programme Maximum load Programme description Temperature range Reference spin speed (Type of load and soil level) 3 kg Mixed fabric (cotton and synthetic 1200 rpm items) Super Eco Cold 9 kg To drain the water in the drum. All fab- rics.
  • Page 10 Programme ■ ■ ■ ■ ■ ■ Economy ■ ■ ■ ■ ■ ■ Synthetics ■ ■ ■ ■ Wool/Handwash ■ ■ ■ ■ ■ ■ Delicates ■ ■ ■ Mix 20° ■ ■ ■ ■ ■ Super Eco ■ Drain ■...
  • Page 11 TIMED DRYING Spin Suggested Dryness Level Type of fabric Load (kg) speed duration (rpm) (mins) Extra Dry Cottons and Linen 1600 225 - 245 For towelling materials (bathrobes, bath towels, etc) 1600 135 - 155 1600 95 - 105 Cupboard Dry Cottons and Linen 1600 215 - 235...
  • Page 12 DRYING LEVEL With this option you can set an automatic level of dryness for the laundry. The display shows the symbol of the set level. • Extra dry level for cotton items • Cupboard dry level for cotton and synthetic items ■...

  • Page 13: Before First Use

    BEFORE FIRST USE 3. Put 2 litre of water in the detergent During installation or before first use compartment for washing phase. you may observe some water in the This activates the drain system. appliance. This is residual water left in 4.
  • Page 14 SETTING A PROGRAMME 2. Extract the detergent dispenser. 1. Turn the programme knob and set the programme: • The related programme indicator comes on. • The indicator of the flashes. • The display shows the level of the Time Manager, the programme duration and the indicators of the programme phases.
  • Page 15 OPENING THE DOOR • The door locks, the display shows the indicator CAUTION! If the temperature and level of the water in the drum are too If the indicator flashes, the door is high and the drum still rotates, you locking.

  • Page 16: Daily Use - Drying Only

    • After 5 minutes from the end of the washing The appliance drains and spins programme automatically after approximately 18 Press the button to activate the appliance hours (except for Wool programme). again. The display shows the end of the last set AUTO STAND-BY OPTION programme.

  • Page 17: Daily Use - Washing & Drying

    • The display shows the door locked • The last minutes of the drying cycle the appliance performs a cooling and anti-crease indicator phase. The door is still locked. If you set only 10 minutes of drying, When the door locked goes off in the display, the appliance performs only a cooling you can open the door.

  • Page 18: Hints And Tips

    The released fluff could stick to the fabrics during If you set only 10 minutes of drying the next cycle. after washing, the appliance calculates To prevent the fluff in your laundry, we recommend also the duration of the anti-crease that you: and the cooling phases.
  • Page 19 DETERGENTS AND ADDITIVES ITEMS NOT SUITABLE FOR DRYING • Only use detergents and additives specially Do not set a drying programme for this made for washing machines: laundry: – powder detergents for all types of fabric, • Synthetic curtains. – powder detergents for delicate fabrics (40 •...

  • Page 20: Care And Cleaning

    CARE AND CLEANING MAINTENANCE WASH WARNING! Refer to Safety chapters. With the low temperature programmes it is possible that some detergent stays in the drum. Perform a maintenance wash regularly. To do this: EXTERNAL CLEANING • Remove all laundry from the drum. •...

  • Page 21: Troubleshooting

    180° CLEANING THE INLET HOSE AND THE VALVE FILTER 45° 20° EMERGENCY DRAIN 1. Disconnect the mains plug from the mains socket. Because of a malfunction, the appliance cannot 2. Close the water tap. drain the water. 3. Put the two ends of the inlet hose in a If this occurs, do steps (1) through (8) of 'Cleaning container and let the water flow out of the the drain filter'.
  • Page 22 First try to find a solution to the problem (refer to • - The mains supply is unstable. Wait until the table). If the problem persists, contact the the mains supply is stable. Authorised Service Centre. • - No communication between electronic With some problems, the acoustic signals elements of the appliance.
  • Page 23 Problem Possible solution • Make sure that the water tap is open. • Make sure that the pressure of the water supply is not too low. For this information, contact your local water authority. • Make sure that the water tap is not clogged. The appliance does not fill •...
  • Page 24 Problem Possible solution • The appliance calculates a new time according to the laundry load. The cycle is shorter than See the ‘Consumption Values’ chapter. the time displayed. The cycle is longer than • An unbalanced laundry load increases the duration time. This is a the time displayed.

  • Page 25: Technical Data

    5. Take out the laundry and then close the appliance door. 6. Close the filter flap. TECHNICAL DATA Dimension Width/ Height/ Depth/ To- 600 mm/ 850 mm/ 605 mm/ 639 mm tal depth Electrical connection Voltage 220-240 V Overall power 2200 W Fuse 13 A...
  • Page 28 WWW.ZANUSSI.COM/SHOP...
