Summary of Contents for Zanussi ZWD 81663 NW
- Page 1 User Manual GETTING STARTED? EASY. ZWD 81663 NW EN User Manual Washer Dryer...
-
Page 2: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 3 Do not install the appliance behind a lockable door, a sliding • door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open. Connect the mains plug to the mains socket only at the end of •...
-
Page 4: Safety Instructions
Do not use the appliance if items have been soiled with • industrial chemicals. Do not dry unwashed items in the wash dryer. • Items such as foam rubber (latex foam), shower caps, • waterproof textiles, and rubber backed articles and clothes, or pillows fitted with foam rubber pads should not be dried in the washer dryer. -
Page 5: Electrical Connection
• When the appliance is in its permanent position, • This appliance is for household use only. check that it is fully level with the aid of a spirit • Do not put flammable products or items that are level. If it is not, adjust the feet accordingly. wet with flammable products in, near or on the appliance. -
Page 6: Product Description
PRODUCT DESCRIPTION APPLIANCE OVERVIEW Worktop Detergent dispenser Control panel Door handle Rating plate Drain pump filter Feet for levelling the appliance INSTALLATION ON SUSPENDED FLOORING HOW TO ACTIVATE THE CHILD SAFETY DEVICE Suspended wooden floors are particularly susceptible to vibration. This device prevents children or pets from being closed in the drum. -
Page 7: Control Panel Description
CONTROL PANEL CONTROL PANEL DESCRIPTION Programme knob Additional rinse (Extra Rinse) Spin reduction (Spin) Automatic drying level (Auto Dry) Temperature (Temp.) Start/Pause (Start/Pause) Display Delay start Drying time (Drying Time) Time save Prewash phase (Prewash) DISPLAY... -
Page 8: Programme Chart
Time area : Programme duration : Selected drying time : Delay start : Alarm codes : Message of error : The programme is completed. Time programme indicators : Normal duration indicator : Quick indicator : Super quick indicator Delay start indicator Child safety lock indicator Door locked indicator Indicators of dryness level... - Page 9 Maximum load Programme Programme description Maximum spin Temperature range (Type of load and soil level) speed 1.5 kg Machine washable wool, hand washable Wool 1200 rpm wool and other fabrics with «hand washing» 40°C - (Cold) care symbol 3.5 kg Delicate fabrics such as acrylics, viscose Delicates 1200 rpm...
- Page 10 Maximum load Programme Programme description Maximum spin Temperature range (Type of load and soil level) speed 1.5 kg A short cycle for synthetic and delicate Miniprogramme 800 rpm items with light soil level or for items to 30°C freshen up. 1) The washing programme Economy at 60ºC with a load of 8 kg and the drying programme Cotton Dry are the reference programmes for the data entered in the energy label, in compliance with EEC 92/75 standards.
-
Page 11: Programmes For Automatic Drying
Programme ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ 1) Only the QUICK option is available. 2) Available only if the last spin speed step is lower than 800 rpm. PROGRAMMES FOR AUTOMATIC DRYING Dryness Level Type of fabric Load Cottons and Linen... -
Page 12: Consumption Values
Spin Suggested Dryness Level Type of fabric Load (kg) speed duration (rpm) (mins) Cupboard Dry Cottons and Linen 1600 155 - 170 For items to be stored (bathrobes, bath towels, etc) 1600 80 - 90 1600 50 - 60 Cupboard Dry Synthetics and mixed fab- 1200 90 - 105... -
Page 13: Drying Time
Energy con- Approximate pro- Water con- Programmes Load (kg) sumption gramme duration (mi- sumption (litre) (kWh) nutes) Economy Cotton Energy Saving Pro- 1.07 gramme 60°C Cottons 40°C 0.85 Synthetics 40°C 0.40 Delicates 40°C 0.50 Wool/Handwash 30°C 0.25 1) «Cotton Energy Saving programme » at 60°C with a load of 8kg is the reference programme for the data entered in the energy label, in compliance with EEC 92/75 standards. -
Page 14: Before First Use
Use this option for persons allergic to detergents You can select: and in areas where the water is soft. • QUICK: to wash items with daily soil. The related indicator comes on. • SUPER QUICK: to wash quickly items with almost no soil. -
Page 15: Detergent Compartments
LIQUID OR POWDER DETERGENT 4. Close the door. 1. Position A for powder detergent (factory setting). 2. Extract the detergent CAUTION! Make sure that no laundry dispenser. stays between the seal and the door. There is a risk of water leakage or damage to the laundry. - Page 16 • The door locks, the display shows the When you use the liquid deter- indicator gent: • When the countdown is completed, the • Do not use gelatinous or thick liq- programme starts automatically. uid detergents. • Do not put more liquid then the You can cancel or change the set of maximum level.
-
Page 17: Daily Use - Drying Only
To drain the water: 1. Press to pause the appliance. 1. Press . The appliance drains the water and 2. Wait until the door lock indicator goes off. spins. 3. Open the door. 2. When the programme is completed, the door 4. -
Page 18: Daily Use - Washing & Drying
The display shows a time value, calculated on the • The drying indicator starts to flash. default load size. If the amount of your laundry is • The display shows the door locked more or less than the default size, the appliance indicator adjusts automatically the time value during the cycle. -
Page 19: How To Remove The Fluff In The Garments
The display shows the indicator . The time value END OF THE PROGRAMME on the display is the duration of the washing + drying cycles, calculated on a default load size. The appliance stops automatically. The acoustic signals operate (if they are active). To have a good drying the appliance For more information see "At the end of the drying does not let you set a too low spin... - Page 20 • Remove hard stains with a special detergent. • To use the correct quantity of detergent, check • Wash and pre-treat heavy soil stains before the water hardness of your domestic system. putting items in drum Refer to "Water hardness". •...
-
Page 21: Care And Cleaning
• speed of the last spin Experience will help you to dry the laundry better. • dryness level Take note of the duration of the cycles done before. • type of laundry To avoid the static charge at the end of the drying •... - Page 22 CLEANING THE DRAIN FILTER WARNING! Do not clean the drain Repeat the steps 2 and 3 until the filter if the water in the appliance is water stops flowing out. hot. Regularly check the drain pump filter and make sure that it is clean. 180°...
-
Page 23: Troubleshooting
5. When the drain pump is empty, install the inlet WARNING! Make sure that the hose again. temperature is higher than 0 °C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures. TROUBLESHOOTING •... - Page 24 Problem Possible solution • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. • Make sure that the connection of the drain hose is correct. • Set the drain option if you set a programme without drain phase. The appliance does not •...
-
Page 25: Emergency Door Opening
Problem Possible solution • Turn the water tap on. • Make sure the drain filter is not clogged. The appliance does not dry • Reduce the laundry load. or does not dry correctly. • Make sure you have set the correct cycle. If necessary ,set again a short drying time. -
Page 26: Environmental Concerns
Electrical connection Voltage 230-240 V Overall power 2200 W Fuse 13 A Frequency 50 Hz Level of protection against ingress of solid particles and IPX4 moisture ensured by the protective cover, except where the low voltage equipment has no protection against moisture Cold water Water supply... - Page 28 WWW.ZANUSSI.COM/SHOP...
