Demonstration circuit 1448 is a Dual DC/DC Converter
with USB Power Manager and Li-Ion Battery Charger
featuring the LTC3455EUF-1. Power may be received
from the USB input, a Wall Adapter, or a battery. DC1448
provides the following functions; 700mA CC/CV timer
terminated charger suitable for Li-ion cells, USB power
manager that ensures compliance with the USB power
specification, two 1.5MHz synchronous step down con-
PERFORMANCE SUMMARY
PARAMETER
Wall Adapter Input Voltage Range
USB Input Voltage Range
Battery Charger
Iout
Float Voltage
Trickle Charge Threshold
Recharge Threshold
USB Current
Input Current 500mA Mode
Input Current 100mA Mode
Input Current Suspend Mode
Buck Converters
Switcher 1
Switcher 2
Hot Swap Output
OPERATING PRINCIPLES
Demo Circuit 1448 manages the power supplies that
would be typical for a USB powered device. Power is in-
put from either the USB cable or an adapter to an inter-
mediate voltage bus. This intermediate voltage is then
used to charge a Li-ion battery and to generate two low
Arrow.com.
Downloaded from
Dual DC/DC Converter with USB
Power Manager and Li-Ion Battery
verters and reset and power button status outputs for
interface with a microprocessor.
The LTC3455EUF-1 is available in a 4mm x 4mm 24-
pin exposed-pad QFN package.
Design files for this circuit board are available. Call
the LTC factory.
