Cooke & Lewis BDW60CL Manual

Built in 60cm
Hide thumbs
Table of Contents

Advertisement

Quick Links

60cm Built in dishwasher
GB IE
60cm Built in dishwasher - Barcode: 5052931258482
WARNING: Read the instructions before using the appliance.
4/7/14 10:51 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BDW60CL and is the answer not in the manual?

Questions and answers

Related Manuals for Cooke & Lewis BDW60CL

Summary of Contents for Cooke & Lewis BDW60CL

  • Page 1 60cm Built in dishwasher GB IE 60cm Built in dishwasher - Barcode: 5052931258482 WARNING: Read the instructions before using the appliance. BDW60CL-C&L-A5-GB-IM-18.indd 1 4/7/14 10:51 AM...
  • Page 2 [06] x 1 [07] x 4 (Prefilled on appliance) [08] x 1 1 : 1 [09] x 1 [10] x 4 (3.9x19mm) [11] x 4 (4x37mm) [12] x 4 (3.9x13mm) BDW60CL 60cm Built in dishwasher BDW60CL-C&L-A5-GB-IM-18.indd 2 4/7/14 10:51 AM...

  • Page 3: Table Of Contents

    Getting started… Your product Before you start Safety detail… more Operation Care and maintenance Troubleshooting Recycling and disposal Technical and legal information Guarantee CE declaration of conformity Appendix... Installation BDW60CL-C&L-A5-GB-IM-18.indd 3 4/7/14 10:51 AM...

  • Page 4: Bdw60Cl-C&L-A5-Gb-Im-18.Indd

    Your product BDW60CL 60cm Built in dishwasher Your product Upper spray arm Lower spray arm Filters Rinse aid dispenser Detergent dispenser Cutlery basket Lower basket Upper basket Top sprayer Installation guide located at the end of the guidebook You will need BDW60CL-C&L-A5-GB-IM-18.indd 4...

  • Page 5: Before You Start

    Before you start BDW60CL 60cm Built in dishwasher Before you start • Please read these instructions carefully before using this appliance. The instructions contain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.

  • Page 6: Safety

    Safety BDW60CL 60cm Built in dishwasher Safety Note! The appliance was designed for domestic use inside the house. It is not intended for commercial or industrial use. Before switching on the appliance for the first time Do… Make sure all packaging is removed.
  • Page 7 Safety BDW60CL 60cm Built in dishwasher Do not… Install or use the appliance where the ambient temperature is below 5°C. Use multi-plug adapters or extension cables. Put flammable products or items that have been wet with flammable products in, near or on the appliance.
  • Page 8 Safety BDW60CL 60cm Built in dishwasher Do not… Leave the door in the open position since this could present a tripping hazard. Allow children or pets near dishwasher when the door is open. Sit or stand on the open door.

  • Page 9: In More Detail

    BDW60CL 60cm Built in dishwasher Operation Control panel On/off indicator and option indicator On/off button Programme/Reset button Programme indication Option indication Option button Option change button Time & Info display Low salt/rinse indicator and water indicator BDW60CL-C&L-A5-GB-IM-18.indd 9 4/7/14 10:51 AM...
  • Page 10 Operation BDW60CL 60cm Built in dishwasher Status indication Activate this option only when you use the combi detergent tablets. This option decreases the flow of rinse Multitab aid and salt. Related indication. The programme duration can increase. Use this option if you have only a few items to wash.
  • Page 11 Operation BDW60CL 60cm Built in dishwasher Programmes The water pressure and temperature, the variations of the mains supply, the options and the quantity of dishes can change the programme duration and performance. Consumption values are measured under standard conditions. The display always shows the related programme duration.
  • Page 12 Operation BDW60CL 60cm Built in dishwasher Programme consumption Energy Water Cycle Programme Consumption Consumption Programme Time in Type min. in kWh in ltr 1) * Automatic 115-165 1,05-1,65 9,5-15,5 Intensive 1,45 12,5 2) * 0,94 10,0 Glass 120-140 1,05-1,20 9,5-12,5...

  • Page 13: Water Softener

    Operation BDW60CL 60cm Built in dishwasher Water softener Hard water contains a high quantity of minerals that can cause damage to the appliance and bad washing results. The water softener neutralises these minerals in coaction with salt specifically designed for a dishwasher.

  • Page 14: How To Fill The Salt Container

    Operation BDW60CL 60cm Built in dishwasher Different settings for water softener There are 2 different softener settings related to the used kind of detergent: Detergent powder setting • The salt is added from the water softener only. OFF the multitab option is off.

  • Page 15: How To Fill The Rinse Aid Dispenser

    Operation BDW60CL 60cm Built in dishwasher How to fill the Rinse Aid dispenser Caution! Only use rinse aid for dishwashers. Other product can cause damage to the appliance! Note! The rinse aid is added during the last rinsing phase. It helps to dry the dishes without streaks and stains.
  • Page 16 Operation BDW60CL 60cm Built in dishwasher How to adjust a default setting To get best results in each programme there are well defined specific default settings. If there is no special requirement default settings are recommended. You may adjust three default settings in one menu: Rinse aid dosage, buzzer ON/OFF (sound at programme end), water softener setting.

  • Page 17: Using The Dishwasher

    Operation BDW60CL 60cm Built in dishwasher Using the dishwasher Open the water tap. Press the ON/OFF button to activate the appliance. • If the salt indicator is on, fill the salt container right to the top. Press and hold the RESET button for 3 seconds to confirm the refilling of softener salt.
  • Page 18 Operation BDW60CL 60cm Built in dishwasher Load the baskets Note! With delicate glasses and porcelain make sure they are labelled "dishwasher-proof". Do not put in the appliance items made of wood, horn, aluminium, pewter copper or cast iron. Do not put in the appliance items that can absorb water (sponges, household cloths, etc).

  • Page 19: Cutlery Basket

    Operation BDW60CL 60cm Built in dishwasher Cutlery basket Mix spoons with other cutlery to prevent them bonding together. Place cutlery with the points down for reasons of safety. Place long items in a horizontal position so the spray arms can move freely.
  • Page 20 Operation BDW60CL 60cm Built in dishwasher Lift basket Pull out the upper basket. Hold the basket on both sides on the edge above the lever. Lift the basket till you hear a click. Push down the basket with light pressure to check secure adjustment.

  • Page 21: Bottom Basket

    Operation BDW60CL 60cm Built in dishwasher Bottom basket Place heavily soiled items (like pots and pans or dinner plates) in the bottom basket. The more powerful spray jets provide a better dish washing result. Note! If you hear knocking noises during operation: Check spray arm clearance and that your dishes and glassware are in a firm position.

  • Page 22: Care And Maintenance

    Operation BDW60CL 60cm Built in dishwasher Care and maintenance End of programme When the programme is completed, you will hear an acoustic signal. Open the appliance door. • Optional: Press ON/OFF button to switch off the appliance. • For better drying results, keep the appliance door ajar for some minutes.

  • Page 23: Cleaning The Filters

    Care and maintenance BDW60CL 60cm Built in dishwasher Cleaning the filters Note! Dirty filters and clogged spray arms will result in poor washing results. Make a check regularly and, if necessary, clean them. Turn the filter A anti-clockwise and remove it.
  • Page 24 Care and maintenance BDW60CL 60cm Built in dishwasher Cleaning the spray arms Note! If the holes in the spray arms are clogged, you can remove the spray arms for more easy cleaning. Upper spray arm Turn screw fastening anti clockwise to remove spray arm.

  • Page 25: Troubleshooting

    Troubleshooting BDW60CL 60cm Built in dishwasher Troubleshooting Many problems could be solved by yourself without calling an engineer. In case of malfunction, please check carefully the list and possible solutions below before you contact Customer Services. Problem Possible cause Possible solution The programme Appliance door is open.
  • Page 26 Troubleshooting BDW60CL 60cm Built in dishwasher Washing results are not satisfactory Problem Possible cause Possible solution Remains of food are Dishwasher not loaded Reload the appliance. stuck to the dishes, properly. Water jets cutlery, etc. could not reach all parts of the dishes, etc.

  • Page 27: Recycling And Disposal

    Troubleshooting BDW60CL 60cm Built in dishwasher Recycling and disposal Problem Possible cause Possible solution Smears left behind Amount of rinse-aid set too Adjust the rinse-aid to a on glasses and high. lower setting. cutlery; glasses have acquired a metallic appearance.

  • Page 28: Technical And Legal Information

    Technical and legal information BDW60CL 60cm Built in dishwasher Technical and legal information Given information are based on the European Union‘s standards and rules according to DIR 2010/30/EU. The device meets the European standards and the directives in the current...

  • Page 29: Information For Test Institutes

    Technical and legal information BDW60CL 60cm Built in dishwasher Information for Test Institutes Loading patterns, Soiling according to EN 50242 / IEC 60436 Test Conditions Soiling Cutlery / Soiling Test programme: Eco 50 °C a = milk C = Teaspoon...
  • Page 30 Technical and legal information BDW60CL 60cm Built in dishwasher Information for Test Institutes Upper basket with Knife Rack Knife Rack 14 Knifes 13 Forks Cutlery basket Cutlery basket loading pattern BDW60CL-C&L-A5-GB-IM-18.indd 30 4/7/14 10:51 AM...

  • Page 31: Guarantee

    Guarantee BDW60CL 60cm Built in dishwasher Guarantee This appliance is covered by a full manufacturer’s 2 year parts and 2 year labour guarantee and covers all parts and labour costs associated with the repair of the appliance in a domestic environment. We will repair any defect that arises due to faulty materials or workmanship and use genuine manufacturers parts.
  • Page 32 Guarantee BDW60CL 60cm Built in dishwasher Guarantee Exclusions to the guarantee This guarantee does NOT cover: Appliances that have been damaged or neglected as a result of failure to store, assemble, install, use or care of the products in accordance with the manufacturer’s instructions - GAA will not accept responsibility under this...

  • Page 33: Ce Declaration Of Conformity

    CE declaration of conformity BDW60CL 60cm Built in dishwasher CE Declaration of conformity MANUFACTURER: CATA C/ Ter nº 2, Torelló 08570 - Barcelona (Spain) ADDRESS: We hereby certify that the mentioned accessory complies with the essential requirements of the European Directives applicable, including their modifications and the corresponding transpositions from the national law.

  • Page 34: Installation

    665mm 2 - 6 kg Make sure that the dimensions of the recess agree with the dimensions in the drawing above. Put the appliance adjacent to a water tap, water drain and power supply. BDW60CL-C&L-A5-GB-IM-18.indd 34 4/7/14 10:51 AM...
  • Page 35 [05] x 1 [05] Firstly take off the water-proof plastic from the sticker [05] with the appliance. Secondly stick it on the bottom of the kitchen board. All of this can avoid humidity in the kitchen. BDW60CL-C&L-A5-GB-IM-18.indd 35 4/7/14 10:51 AM...
  • Page 36 Note! Once the appliance is level, check the door closes and seals correctly. Screw the appliance to the work top or to the adjoining units. Caution! Screw tightly to ensure the appliance does not tip. BDW60CL-C&L-A5-GB-IM-18.indd 36 4/7/14 10:51 AM...

  • Page 37: Fully Integrated

    16mm - 24mm Height min. 665mm Weight min. 2,0kg/max 6kg Prepare the door according to the installation template supplied. Close the appliance door. Hang the cabinet door to the appliance door using the cut out. BDW60CL-C&L-A5-GB-IM-18.indd 37 4/7/14 10:51 AM...
  • Page 38 Open the door about 30° and lift the door till it comes loose. • Repeat step 2 to 4. [11] x 4 [11] 2 mm 12 mm Open the door and tighten the screws [11]. BDW60CL-C&L-A5-GB-IM-18.indd 38 4/7/14 10:51 AM...
  • Page 39 The dishwasher should now be screwed to the underside of the worktop, via the two fixing holes in the top trim. Secured to the appliance using the two screws (left & right) [10] at the top of the appliance. BDW60CL-C&L-A5-GB-IM-18.indd 39 4/7/14 10:51 AM...
  • Page 40 (u-bend fixing screw is not provided). Note! The free end of the hose must be at a height between 40 and 100 cm and must not be immersed in water. BDW60CL-C&L-A5-GB-IM-18.indd 40 4/7/14 10:51 AM...
  • Page 41 Refer to "Safety" section. The socket must be attached near the dishwasher and be freely accessible. For electrical requirements refer to "Technical and legal information" section. Connect the power plug to the mains socket. BDW60CL-C&L-A5-GB-IM-18.indd 41 4/7/14 10:51 AM...
  • Page 42 BDW60CL-C&L-A5-GB-IM-18.indd 42 4/7/14 10:51 AM...
  • Page 43 BDW60CL-C&L-A5-GB-IM-18.indd 43 4/7/14 10:51 AM...
  • Page 44 B&Q plc, Chandlers Ford, Hants, SO53 3LE United Kingdom www.diy.com BDW60CL-C&L-A5-GB-IM-18.indd 44 4/7/14 10:51 AM...
