Cotech 52008x36 Instruction Manual

Outdoor IP44 Receiver Switch
Art.no 36-6013 Model 52008x36
Please read the entire instruction manual before using
the product and then save it for future reference.
We reserve the right for any errors in text or images and
any necessary changes made to technical data.
In the event of technical problems or other queries,
please contact our Customer Services.
Operation
Installation
1. Plug the receiver into
an electrical outlet.
2. Hold in the button on
the front of the receiver
for at least 3 seconds
and then release it.
3. The button's LED will
begin flashing slowly.
The receiver is now
ready to be paired with
a transmitter.
4. Pair the receiver to
the transmitter by
following the instructions
accompanying your
transmitter. Up to 6
transmitters can be
paired with the receiver.
5. Plug a light into
the receiver and check
that it is turned on.
6. The light can now be
controlled by using
a transmitter.
GREAT BRITAIN • CUSTOMER SERVICE tel. 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk
Note: The light can also be switched on/off manually by
pressing the button on the receiver.
Unpairing all paired transmitters
1. Hold in the button on the front of the receiver for
6 seconds until the LED button starts flashing quickly.
2. When the LED stops flashing, all the transmitters
which were paired with it will have been unpaired.
Unpairing one paired transmitter
1. Hold in the button for 3 seconds on the front of
the receiver you wish to unpair and then release.
2. The LED button will start flashing slowly. The receiver
is now ready to unpair from the transmitter.
3. Press in the [ OFF ] button on the transmitter
(make sure to choose the correct [ OFF ] button if
the transmitter can connect to multiple receivers).
The transmitter will now unpair from the receiver.

Care and maintenance

• The receiver should be unplugged from the wall
socket if it is not to be used for a long time.
• The receiver should be cleaned by wiping it with
a dry cloth.

Troubleshooting guide

The receiver • Has the receiver been paired with
is not a transmitter as described above?
working, Try pairing them again.
the LED is • Check that the light is properly
not lit. plugged into the receiver and that
it is switched on and not faulty.
• Try plugging the light into another
electrical outlet to make sure that
it works.
• Is there electricity at the outlet
where the receiver is
plugged into?
Responsible disposal
This symbol indicates that this product
should not be disposed of with general
household waste. This applies throughout
the entire EU. In order to prevent any
harm to the environment or health hazards
caused by incorrect waste disposal, the
product must be handed in for recycling so
that the material can be disposed of in a responsible
manner. When recycling your product, take it to your
local collection facility or contact the place of purchase.
They will ensure that the product is disposed of in an
environmentally sound manner.

Specifications

Mains power supply 230 V AC, 50 Hz
433.92 MHz
Frequency
Max range 25 m
Load (resistive bulb) 0–3680 W
Load (inductive) 0–613 W
