- Page 1 User and Installation Manual for Models UN0815A-1A and UF0915A-1A UN1215A-1A and UF1415A-1A UN1520A-1A and UF2020A-1A...
-
Page 2: Table Of Contents
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Introduction The design of this product is the result of years of experience in developing commercial ice machines. It has been designed for simple operation in a wide range of locations. Please follow the instructions for installation and maintenance to get the most use from this ice machine. -
Page 3: Important Details
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Important Details Warranty: The machine is designed for use indoors in a controlled environment. It must be kept dry, not The warranty statement for this product is provided overheated or subjected to excessive cold. The water separately from this manual. -
Page 4: Pre-Installation
Model Electrical Ice Form Width Depth Height (w/o legs) Power (volts/Hz/Phase (in / cm) (in/cm) (in/cm) Cord UN0815A-1A 115/60/1 Nugget 15 / 38 23.7 / 60.3 31.94 / 81.1 5-15P UN1215A-1A 115/60/1 Nugget 15 / 38 23.7 / 60.3 31.94 / 81.1... -
Page 5: Unpacking And Setup
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Unpacking and Setup Remove all shipping and packing materials that may be in the ice storage bin. The unit can be installed with or without legs. The cabinet is equipped with small bumpers on the base to allow placement without legs. -
Page 6: Cabinet Layout, Un0815, Un1215, Uf0915, Uf1415
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Cabinet Layout, UN0815, UN1215, UF0915, UF1415 60.3cm 23.7in POWER CORD POTABLE WATER INLET 1/4" OD. PLASTIC TUBING (5ft) 38.1cm 15.0in DRAIN 3/4" FPT 81.1cm 31.9in 95.4cm 37.6in 68.9cm 27.1in 10.2cm 4.0in MINIMUM UTILITY CLEARENCE... -
Page 7: Back View, Un0815, Un1215, Uf0915, Uf1415
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Back View, UN0815, UN1215, UF0915, UF1415 POWER CORD POTABLE WATER INLET 1/4" OD. PLASTIC TUBING (5ft) DRAIN 15.8cm 3/4" FPT 6.2in 3.7cm 1.5in 19.1cm 7.5in October 2019 Page 7... -
Page 8: Cabinet Layout, Un1520, Uf2020
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Cabinet Layout, UN1520, UF2020 POWER CORD 60.1cm 23.67in POTABLE WATER INLET 1/4" OD. PLASTIC TUBING (5ft) 50.8cm 20.00in DRAIN 3/4" FPT 81.1cm 31.94in 95.4cm 37.56in 10.2cm 4.00in 68.9cm MINIMUM 27.13in UTILITY CLEARENCE 15.2cm 6.00in... -
Page 9: Back View, Un1520, Uf2020
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Back View, UN1520, UF2020 POWER CORD POTABLE WATER INLET 1/4" OD. PLASTIC DRAIN TUBING (5ft) 3/4" FPT 15.8cm 6.21in 2.75in 3.7cm 1.46in 3.17in 32cm 12.61in October 2019 Page 9... -
Page 10: Component Location
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Component Location All models are essentially automatic and require very little contact other than routine cleaning. Float Valve Lever The cleaning process does require understanding of certain components. They include the on and off buttons, condenser fins, water reservoir and ice breaker. Reservoir Ice Sweep Ice Breaker... -
Page 11: Connect The Water Supply
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Connect the Water Supply Plumbing information: • The water supply connection is at the back panel. Connection Information: It is a 5’ (1.5 meter) 1/4 inch (6.35 mm) OD Important: connect to potable water supply only. plastic tube. -
Page 12: Connect The Power
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Connect the Power This is a cord-connected unit, and must be connected to its own dedicated power supply. Check the dataplate on the back of the machine to confirm the voltage and per the dataplate use fuses or HACR circuit breakers. -
Page 13: Initial Start Up
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Initial Start Up 1. Remove the front panel by removing the two screws holding it to the cabinet and pulling the panel down and off the machine. 2. Turn on the water supply, correct any leaks. 3. -
Page 14: Use And Operational Notes
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Use and Operational Notes To use, simply lift the door by its bottom edge and slide it up and into the top of the machine. Use the scoop to remove ice and close the door. The machine will make the most ice if it has plenty of room to breathe. -
Page 15: Maintenance: Cleaning The Water System
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Maintenance: Cleaning The Water System Frequency: Recommended about twice a year. Units that are used heavily or are on highly mineralized water may require more frequent cleaning. Cleaning this machine involves adding a solution of scale remover and water to the ice machine and continuing to add it as it makes ice. - Page 16 UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual 14. After ice making starts, continuously add scale remover solution to the reservoir to keep it about half full. 15. When all remaining solution is used, rotate the float valve lever to the ON position. Ice will continue to be made.
-
Page 17: Cleaning The Condenser
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Cleaning the Condenser 1. Remove the front panel. Other maintenance 2. Push and hold the OFF button until the machine Clean the optical sensors. stops and / or the Status light is not glowing. 1. - Page 18 UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Other maintenance Clean the optical sensors. 1. Mix solution of 4 ounces of Clear 1 Ice Machine 4. Use cotton swab and cleaning solution to Scale Remover and 1.5qt/1.4L of 90 F/32 C to thoroughly clean photo sensor lens...
-
Page 19: Before Calling For Service
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Before Calling For Service No ice – check water supply. Restore water supply to unit if shut off. Remove front panel and check water indicator light, if ON, the unit is not sensing water. Note: Unit will automatically restart when the water supply is restored. -
Page 20: Wiring Diagram
UF0915, 1415, 2020 and UN0815, 1215, 1520 User Manual Wiring Diagram October 2019 Page 20... - Page 21 SCOTSMAN ICE SYSTEMS 101 Corporate Woods Parkway Vernon Hills, IL 60061 847-215-4500 www.scotsman-ice.com 17-3688-01...
