Technical Service Training
UC2024 and UC2724

Advertisement

loading
Need help?

Need help?

Do you have a question about the UC2024 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Scotsman UC2024

Summary of Contents for Scotsman UC2024

  • Page 1 Technical Service Training UC2024 and UC2724...

  • Page 2: Service Support

    Service Support Technical Service 1-800-533-6006 Check out our mobile ready website www.scotsman-ice.com/service...
  • Page 3 Technical Service Virtual Business Card...
  • Page 4 Training Agenda • Introduction • Installation • Operation • Maintenance • Diagnostics • Taking the unit apart...
  • Page 5 UC2024 and UC2724 • Cubed Ice Making – 24 inches wide – 39 inches high including legs – Air or Water Cooled – Airflow in and out of the front...

  • Page 6: Component Location

    Component Location Air Filter...
  • Page 7 Component Location Ice Storage Bin Control Box Fan Motor...
  • Page 8 Component Location Slide Out Electrical Box Contactor Transformer Controller Lights and Buttons Master Switch...
  • Page 9 Component Location Drain Hose...
  • Page 10 Component Location Back Panel Area Power Cord Water Valve Pump Drain Compressor...
  • Page 11 Component Location Side Views Flap Switch Evaporator Thermistor...
  • Page 12 Component Location Evaporator Water Distributor Ice Chute Ice Sensing Flap...
  • Page 13 Component Location Overflow Standpipe...
  • Page 14 Component Location Water Distributor Snaps In / Out Back View of Distributor / Spray Bar...
  • Page 15 Component Location Ice Chute Ice Chute...
  • Page 16 Component Location Ice Sensing Flap Flap Open (Freeze) Magnet Flap Closed (Harvest or Bin Full)
  • Page 17 Component Location Ice Sensing Flap and Switch...
  • Page 18 Installation - Utilities • Recessed area – Power cord • 5-15P plug – Water fitting • 3/8” FPT inlet on 60Hz • Remember to flush the line! – Drain fitting • 3/4” FPT • Vent horizontal runs...
  • Page 19 Water Filtration and Treatment • Taste and Odor Filters – Use if water has objectionable taste – This type contains activated carbon – T&O Filters remove chlorine • Chlorine frequently added by water treatment plant to kill bacteria • Risk of increased bacteria growth by using a Taste and Odor filter –...

  • Page 20: Installation

    Installation • Place in planned location – Must have water, drain and power nearby • Level the unit – Use the included legs • Leg thread is 5/8 – 11 – Or seal the cabinet to the floor • Rubber bumpers on the bottom reduces floor damage...

  • Page 21: Pre-Start Check

    Pre-Start Check • Remove front panel • Remove shipping block under fan motor bracket • Check for any other shipping materials...

  • Page 22: Installation - Start Up

    Installation – Start up • Turn on water supply – Confirm no leaks • Connect power, move master switch to ON – Anti-Slush light blinks for 90 seconds – After that, the unit will move to Harvest mode for 90 seconds •...
  • Page 23 Installation – Start up • Check bin control for shut off – Move flap to closed and then open – See the Bin Full light blink • Pour water in bin, check draining • Return front panel to unit...
  • Page 24 Controller • Four Status Lights – Timer – Freeze – Bin Full – Anti-Slush • Ice Bridge Thickness Degree Lights – More lights = Thicker Ice...
  • Page 25 Ice Thickness Degree Lights • 10 settings on 5 lights • 1 blinking is minimum, 5 steady is maximum – Steady light = 2 – Blinking light = 1 • Examples – 3 lights on steady = 6 – 3 lights steady, 1 blinking = 7 •...
  • Page 26 Normal Bin Full...
  • Page 27 UC2024 Operation R-134a (PSIG) Conditions Suction, just Max Discharge Cycle Time Freeze Cycle Harvest Cycle before harvest in harvest (minutes) (minutes) (seconds) (minutes) (seconds) 70/50 6 - 7 15 - 16 14 - 15 90/70 6 - 7 19 - 20...
  • Page 28 (seconds) 70/50 3 - 4 52 - 54 13 - 14 12 - 13 90/70 4 - 5 65 - 68 17 - 18 16 - 17 Model Compressor Amps UC2024 6 – 6.5 Data is for new, clean machines...
  • Page 29 Example Cycle System Pressures 70/50 Time Suction Discharge...
  • Page 30 Example Superheat Superheat, Degrees F Time...

  • Page 31: Maintenance

    Maintenance • Flush out drain • Clean Filter - Pull air filter out – Wash off, dry and return – Also in water cooled • For appearance only...

  • Page 32: Water System Maintenance

    Water System Maintenance • Scale Removal • Sanitizing...

  • Page 33: Scale Removal

    Scale Removal • Remove front panel • Move master switch to OFF • Discard ice • Drain sump...
  • Page 34 Scale Removal • Drain water system – Pull sump drain hose plug – Reconnect hose plug when done...
  • Page 35 Scale Removal • Mix a solution of 5 oz or 150 cc of Scotsman Clear 1 Scale Remover and 2.5 quarts or 2.4 liters of clean, warm potable water. • Do NOT mix any stronger!
  • Page 36 Scale Removal • Remove water distributor and ice chute from unit. • Wash them with the scale remover solution and return them to the unit.
  • Page 37 Scale Removal • Pour the scale remover mixture into the sump...
  • Page 38 Scale Removal • Move the master switch to Wash • Operate the unit in the Wash mode for 20 minutes or more • Move the master switch to OFF...
  • Page 39 Scale Removal • Drain water system – Pull sump drain hose plug – Reconnect hose plug when done...
  • Page 40 Scale Removal • Check water distributor for any remaining scale, repeat cleaning if needed. • Wash the bin with scale remover solution. • Flush the bin drain with hot water.
  • Page 41 Sanitization • Use locally approved sanitizer. – Mix 2 to 2.5 gallons of solution per directions of the sanitizer – Pour sanitizer solution into sump until full – Move master switch to Wash – Operate the unit in Wash for 10 minutes –...
  • Page 42 Sanitization • Drain water system – Pull sump drain hose plug – Reconnect hose plug when done...
  • Page 43 Sanitization • Move master switch to ON to restart ice making • Make a batch of ice • Pour hot water into bin to melt ice until ice is gone • Reattach all panels...
  • Page 44 Sources of Ice Machine Service...
  • Page 45 Diagnostics • No Ice – No water in sump • Check for – Plugged water filter – Inlet water solenoid valve not opening...
  • Page 46 Diagnostics • No Ice – All components operating • Check for – Inlet water valve leaks through – Hot gas valve leaks through • Water is warm...
  • Page 47 Diagnostics • No Ice – In freeze, anti-slush light is OFF – Water in sump – No water over evaporator • Water is part of the recipe! – Check pump • Move master switch to Wash • Check for water over plate, if none, check voltage at pump •...
  • Page 48 Diagnostics • No Ice – Bin full light is ON: False bin full • Check for – Flap in closed position – Flap switch stuck closed • Note: Labeled curtain switch in wiring diagram...
  • Page 49 Diagnostics • Makes ice, but much too large or too small • Check for – Cube size set to incorrect size – Thermistor failure • Operating on timed cycles • Indicated by all cube size and harvest time lights are flashing...
  • Page 50 Diagnostics • No ice in bin – Makes ice, but does not release from plate • Check for – Ice bridge too large – Hot gas valve not opening – Evaporator plate damaged...
  • Page 51 Diagnostics • No ice – Air cooled fan not turning • Check for – Open windings on fan motor – Seized fan motor – Fan pressure control not closing • opens at 100 PSIG, auto reset closed at 150...
  • Page 52 Diagnostics • No ice – Unit in ice making mode (freeze light is ON) but contactor is not pulled in • Check for – Open contactor coil – No power to contactor from controller – High pressure cut out open •...
  • Page 53 Diagnostics • No ice – Compressor off, pump forcing water over evaporator • Check for – Overheating • Low charge • High superheat – Contactor coil open – Compressor not starting • Start relay or PTCR • Start capacitor • Motor windings...

  • Page 54: Test Mode

    Test Mode • To use test mode (pump will be off in Test Mode): Place both thermistor probes in 32 o F. water. – – Push and hold the left plus (+) button and the lower right minus (-) button for at least 5 seconds.
  • Page 55 Taking the Unit Apart • Remove front panel • Drain water system...
  • Page 56 Taking the Unit Apart • Remove top panel – Three thumb screws at back – Push panel back slightly – Lift up and off...
  • Page 57 Taking the Unit Apart • Bin is not removable • Removing left, right and back panels helps with access • Water inlet solenoid valve is at the back • Hot gas valve is at the back • TXV is at the back...
  • Page 58 Taking the Unit Apart • Flap/Curtain switch is under the right side panel...
  • Page 59 Taking the Unit Apart • Water thermistor is at the back • Water pump is at the back • Evaporator thermistor is under the left panel...
  • Page 60 Taking the Unit Apart • Water pump...
  • Page 61 Taking the Unit Apart • Evaporator...
  • Page 62 Taking the Unit Apart • Compressor – Behind lower back panel...
  • Page 63 Taking the Unit Apart • Fan – Removable from the front and with the left panel off – Access holes for easy access to back screws...
  • Page 64 Technical Service: 1-800-533-6006 www.Scotsman-ice.com...
  • Page 65 Questions?
