Exibel L402-A-UK Instruction Manual

A4 Laminator
Art.no 18-4534 Model L402-A-UK
34-1401 L402-A
Please read the entire instruction manual before using and save it for
future use. We apologise for any text or photo errors and any changes
of technical data. If you have any questions concerning technical
problems please contact our Customer Service Department.

Safety

• Unplug the lead before cleaning.
• The laminator may not be used by children without the supervision
of an adult.
• Do not insert any metal objects like paperclips, coins, etc.
into the machine.
• Do not insert anything other than lamination film into the machine.
• Do not disassemble the laminator or attempt to repair it yourself.
The laminator must not be modified in any way.
• The laminator may produce a burnt odour when first used.
This is completely normal.
• Do not touch any of the machine's hot surfaces. Burn injuries
may result.
• Never use the laminator in humid environments or near sources of water,
such as sinks, taps, etc.
• The mains lead should be checked regularly. Never use the product
if the mains lead or its plug is damaged or if the product is not
functioning properly.
• If the mains lead is damaged, it must only be replaced by a qualified
service technician in order to prevent any risk of fire or electric shock.
• Never lay the mains lead over hot surfaces or pull it round sharp
edges or corners. Position the mains lead in such a way that it will
not be trodden on or tripped over.

Product description

• Two rollers
• Capacity: 250 mm/min 80–100 µm, max A4
• 3-min warm-up time
• Max. paper thickness: 0.5 mm

• Reverse feature for correcting misfeeds

• Power output: 210 W
GREAT BRITAIN - CUSTOMER SERVICE contact number: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk postal: 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
English
1 2 3 4
1. Film feed slot
2. [ 0/1 ] Power switch
3. POWER Red LED indicator
4. READY Green LED indicator
5. [ ABS ] Reverse function
6. Output chute

Operation

Make sure the power switch (2) is set to 0 before plugging it into
a wall socket.
1. Plug it into a wall socket and set the power switch (2) to the I position.
The red LED (3) will light to indicate that the warm-up phase has begun.
2. The green LED will light after about three minutes indicating
that the laminator is ready for use. Make sure that there is
sufficient room behind the machine to allow the lamination to exit
the machine freely.
3. Flip open the lamination film and insert the paper to be laminated.
Allow at least 3–10 mm clearance at the sealed edge when
inserting. Make sure the paper is not crooked.
4. Feed the sealed end of the lamination film into the feed slot first.
Note: This is very important; otherwise, the lamination film can
become caught in the rollers.
5. Let the entire lamination exit freely. Do not pull it out with force.
Let it cool before handling it. Place a flat heavy object, like a book
over the laminate while cooling if you want your results to be extra
smooth and flat.
6. Set the power switch to 0 and unplug the laminator when you have
finished using it.
Note:
• Select the correct size of lamination film so that it fits the object to
be laminated.
• Avoid placing several small pieces of paper into a single lamination
sheet.
• Remember that the laminate's total thickness may not exceed 0.5 mm.
• Do not feed in empty lamination film.
• Do not cut the lamination film into smaller pieces before feeding it
through the machine.
• Do not feed the film into the machine at an angle. It can become
caught in the machine during the lamination process.
• Use only lamination film. Never try to feed in any other
type of material.
• If you intend to laminate in series, remember the machine needs to
rest at least 15 seconds between every lamination.
5 6
• Do not feed in any material that is sensitive to heat.
The laminator is intended for personal use only and should not be
used continuously. We recommend that you turn off the machine and
let it cool down for approximately 30 minutes after 2 hours of use.
Reverse feature for correcting misfeeds
The machine has a feature which allows the laminate to be pulled out
from the front. If the lamination film misfeeds or jams:
1. Turn off the laminator immediately by turning the power switch to
the 0 position and then unplug it.
2. Hold in the [ABS] button and extract the laminate.

Care and maintenance

Unplug the laminator from the wall socket and wipe it with a soft, damp
cloth when needed. Never use strong detergents or solvents.

Responsible disposal

This symbol indicates that this product should not be
disposed of with general household waste. This applies
throughout the entire EU. In order to prevent any harm to
the environment or health hazards caused by incorrect
waste disposal, the product must be handed in for recycling
so that the material can be disposed of in a responsible
manner. When recycling your product, take it to your local collection
facility or contact the place of purchase. They will ensure that
the product is disposed of in an environmentally sound manner.

Specifications

Rated voltage
Power
Max lamination width
Speed
Recommended
lamination film thickness
Dimensions
220–240 V AC, 50 Hz
210 W, 1.2 A
230 mm
250 mm/minute
80–100 microns
320 × 86 × 86 mm
