Incra TS II Owner's Manual

Micro precision table saw fence
Hide thumbs

Advertisement

Quick Links

Download this manual
CONTENTS
Safety . . . . . . . . . . . . . . . . . . . 2
Fasteners and Hardware Lists . . . . 2
Final Calibration
. . . . . . . . . . . . 9
The only table saw
fence with Automatic
Positioning Control
OWNER'S MANUAL
Please read this owner's manual before use and
keep it at hand for reference.
Note: The INCRA TS II system consists of three
packages. One of the packages contains the rails
and another the base mount unit. These two
assemblies are covered fully by this
owner's manual and pages 2, 3, 6 and 7
of the Ultra 24 owner's manual.
In just about an hour or so, you are going to be
operating one of the most exciting new tools in
today's woodshops. Your table saw will undergo
a transformation, and what was once an average
saw will emerge a precision woodworking
machine, one you'll be proud of for years to
come. So take a few minutes to read over the
safety information and mounting instructions, then
grab a phillips screwdriver and a set of wrenches
and let's get started.
Extension Table
. . . . . . . . . . . . 11
Auxiliary Fence Mounting
Maintenance . . . . . . . . . . . . . . 12
Product Information . . . . . . . . . . 12
Warranty . . . . . . . . . . . . . . . . . 12
TM
owner's manual. The
third package contains
the INCRA Jig Ultra 24.
Read all of this TS II
. . . . . 12

Advertisement

loading
Need help?

Need help?

Do you have a question about the TS II and is the answer not in the manual?

Questions and answers

Related Manuals for Incra TS II

Summary of Contents for Incra TS II

  • Page 1 OWNER’S MANUAL Please read this owner’s manual before use and keep it at hand for reference. Note: The INCRA TS II system consists of three packages. One of the packages contains the rails and another the base mount unit. These two assemblies are covered fully by this owner’s manual.
  • Page 2 SAFETY Important safety instructions for using the INCRA TS II. Before using the INCRA TS II, read and follow all of Always keep both hands behind the fence when the instructions and safety information in this manu- moving the INCRA TS II to a new setting.
  • Page 3 Rail Hardware Pack Base Mount and Fence Glide Hardware Pack ⁄ ⁄ " – 20 x ⁄ " socket head cap screw flat washer ⁄ " flat washer " #10 – 32 x 1 ⁄ " phillips pan head screw o.d.

  • Page 4: Rail Assembly

    Note: The blade guard must be reinstalled after you have fin- (See Details 1A and 1B) ished mounting the INCRA TS II to your table saw. Attach mounting brackets Attach (4) mounting brackets to the cast iron surface of your table saw using the supplied hardware.
  • Page 5 Set final mounting bracket position FIG. 4 First: Clamp base clamps to Clamp the (2) TS II base clamps to the front rail as rail. Use clamp pads to avoid Set final mounting marring anodized surfaces shown in Fig. 4 and loosen the bolts that secure the mount- bracket position ing brackets to your table saw.

  • Page 6: Base Mount Assembly

    Base support bars Base sup- ⁄ " port bar Attach INCRA Jig Ultra to base FIG. 10 support bars and loosely attach Attach ULTRA to remaining base clamp base support bars Open the Ultra Mounting Hardware Pack. Place #10 #10–...

  • Page 7: Miter Slot

    Align base mount FIG. 11 Miter slot assembly parallel to Align base mount assembly Base sup- miter slot parallel to miter slot Loosen base clamp port bar Take the base mount assembly to the screws as necessary table saw and as you lower the base mount onto the rails, position the (4) clamping knob assemblies directly under the slots in the base clamps.

  • Page 8: Fence Assembly

    Note: When removing the TS II from your table be made, turn off the saw and walk to the rear to saw, always disengage the rail hooks from the make the adjustment. T-slot lip before lifting the TS II off the rails.
  • Page 9 FINAL CALIBRATION Important: As with any table saw fence, FIG. 17 accurate calibration and alignment require that First: Loosen ULTRA mount- Align fence parallel to miter slot the saw blade be aligned parallel to the miter ing screws, align fence then and tighten ULTRA mounting screws retighten screws slots.
  • Page 10 FIG. 20 Second: Tighten Place ULTRA on the rails to Moving your TS II to the left side of the blade can be quite knobs on rear rail only the left of the saw blade useful, especially on table saws which have a blade tilt to the right.

  • Page 11: Blade Guard Adjustments

    If you wish to add a ⁄ " thick table board between the right FIG. 26 hand extension wing of your table saw and the TS II base ⁄ " dia. hole Table board support mount assembly, begin by making the wooden supports shown in Fig.
  • Page 12 LIFETIME WARRANTY ON POSITIONING RACKS If an INCRA positioning rack in this tool becomes damaged for ANY reason, Taylor Design Group will replace it free of charge for as long as you own your tool. Return the damaged rack, transportation pre- paid, and allow 1 to 2 weeks for delivery.
