Technical specifications

Supported Formats 44.1kHz to 3,072kHz PCM up to 32 bits
(Input dependent) 1xDSD, 2xDSD, 4xDSD, 8xDSD
Supports DSD via DoP on all inputs
Digital Inputs 1x XLR
1x Coaxial RCA
2x Toslink
1x Word-Sync Output (BNC)
2x Advanced isolated input module slots
XLR Analog Outputs 3.57Vrms Maximum (Digital Input)
12Vrms Maximum (Analog Input)
Galvanically isolated
Base XLR Output 300 Ohm Balanced (High Gain)
150 Ohm Balanaced (Low Gain)
Base RCA Output 120 Ohm
Volume Control 1dB steps (Range 0 - 106).
Volume Control can be disabled in the
menu.
Display Custom discrete LED audio clock
synchronous display
Adjustable brightness and auto-off
feature
Controls Isolated RS-232
IR Remote
Knob + 3 Buttons
Chassis Dimensions Width: 17 in (432 mm)
Depth: 12 in (305 mm)
Height without feet: 2 in (51 mm)
Stack height: 2.65 in (68 mm)
Weight: 18 lbs (8.2 kg)
Product Feet: M6X1 Thread
Shipping Dimensions Width: 22 in (559 mm)
Depth: 18 in (457 mm)
Height: 7 in (177 mm)
Weight: 27 lbs (12.3 kg)
Included Accessories User Manual
MSB Remote
Micro USB charging cable
4x Rubber Feet
4x Plastic inserts for feet
