MSB Technology The Discrete DAC User Manual page 13

Premier Powerbase Upgrade
The powerbase contains isolation technology. The powerbase
detects the input voltage and switches to 120 volt or 240 volt
operation. It is also available in a fixed 100 volt configuration. All
powerbases have over-voltage protection.
Two fuses are provided:
- 5A 250V SLO BLO - 5 mm x 20 mm miniature fuse (This is the main
fuse).
- 100mA 250V SLO BLO - 5 mm x 20 mm miniature fuse (This is for
the standby supply only).
Powerbase Controls
There is one button on the front of the powerbase as well as two
control features just under the front of the powerbase on the
bottom.
LED
indications
Display
brightness
Power control Normal - This sets the powerbase as the 12 volt
Power Control
Normal
White - Power on.
Red - Power off.
Amber - Linked mode, 12 volt trigger controlled.
Flashing Amber - Over-voltage protection.
This is a rolling wheel to control the brightness of
the power indication light
trigger master.
Linked - This sets the powerbase as the 12 volt
trigger slave. The 'master' powerbase will control
this unit.
Front of Powerbase
Linked
LED Indicator
Power Button
IR Sensor
Display Brightness
Darker Brighter
