RCI 0161 Installation

I N S T A L L A T I O N
1) Mark center line (CL) of existing device latch from active door to inactive door.
2) Mark the mounting holes for the Double Door Housing (DDH) on the inactive door.
3) Drill two 13/32" (0.406") holes through inactive door.
4) Drill wire access hole into desired area of DDH. Pull two (2) wires through the access hole and connect to
strike. (Polarity is not observed)
5) Temporarily mount 0161 strike to DDH through the slotted holes (Hole C) using 1" button head socket cap
screws. (BHSCS)
6) Mount DDH to inactive door using the two (2) 1/4-20x3" screws and 1/4-20" Sex Nuts supplied.
7) Adjust electric strike insert horizontally (If necessary), until Pullman Latch engages when door is closed.
(See Fig. 2 on 0161 installation instructions if further horizontal insert adjustment is necessary)
8) Mark, drill and tap Hole D for 1/4-20x1" BHSCS provided to secure the final location.
IS0161DDH
