PAG PAGlink PL96e User Manual

V-mount intelligent linking batteries
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
V-Mount Intelligent
Linking Batteries
User Guide
U5132V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAGlink PL96e and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PAG PAGlink PL96e

Summary of Contents for PAG PAGlink PL96e

  • Page 1 V-Mount Intelligent Linking Batteries User Guide U5132V...
  • Page 2 Disclaimer The information contained in this document is correct at the time of publication. PAG Ltd. reserves the right to change specifications or product details without notification. Changes to product details will be incorporated in the next version of the document. PAG updates documents on a regular basis.

  • Page 3: Table Of Contents

    Contents Section Page Introduction Specification Charging Discharging Storage Thank you for choosing PAGlink V-Mount Intelligent Run-Time, Capacity & Data Linking Batteries. Please read the important safety Battery Protection Features information and instructions before using your PAGlink Features battery. Safety Information 10 Servicing 11 Recycling 12 Guarantee...

  • Page 4: Introduction

    Sony V-Mount specification. There is a choice between 96Wh and 150Wh capacities, and a choice between a 5-light and a numeric Run-Time & Capacity Display. Model Name Capacity Display 9303 PAGlink PL96e 96Wh 5-Light 9304 PAGlink PL96T 96Wh Numeric 9308...
  • Page 5 USB output. 1.13 PAGlink battery and charger firmware can be updated easily by the PL16 Charger - 16 batteries PowerHub - Provides outputs customer, via external contacts, using an update tool provided by charged simultaneously to power camera accessories PAG.

  • Page 6: Specification

    2. Specification Cell Technology: Premium-grade Lithium-Ion sealed rechargeable Storage: cylindrical cells. -10°C to +40°C Optimum 0°C to +20°C +14°F to +104°F Optimum +32°F to +68°F Capacities: Dimensions (L x W x H): Models 9303 & 9304: 133mm (5.2") x 84mm (3.3") x 50mm (1.9") Nominal 6.5 Ampere-hours (96 Watt-hours).

  • Page 7: Charging

    4 x 150Wh batteries 9 hrs of each other to be charged fully): 6 x 150Wh batteries 13 hrs 9702VR PAG RMC4X Charger 4 positions, 4 batteries on each 8 x 150Wh batteries 18 hrs 16 x 150Wh batteries 36 hrs Constant-voltage V-Mount Li-Ion chargers of other reputable manufacturers are also suitable.

  • Page 8: Discharging

    4. Discharging The batteries incorporate a precision fixed end-of-discharge cutoff set Computer Reset to 12.5V, as measured by the battery. This cutoff will only operate if The battery features a computer reset function. In exceptional the battery capacity is less than 5%, eliminating unwanted operation circumstances, a computer reset may be required.

  • Page 9: Storage

    5. Storage For the short term, PAGlink batteries can be left stacked on a charger until required; the charger will keep them topped-up ready for use. For long-term storage, batteries should be in a half-charged state (between 20% and 80%), and unlinked. Storing batteries linked accelerates the rate at which they self-discharge.

  • Page 10: Run-Time, Capacity & Data

    6. Run-Time, Capacity & Data The Numeric Display: The 5-Light Display: The battery is able to display a numeric run-time prediction against The battery is able to indicate a run-time prediction, against load, load, and charge status as a percentage. and charge status as a percentage.
  • Page 11 6. Run-Time, Capacity & Data In-Viewfinder Battery Status Battery status can be shown as a percentage of available capacity in the viewfinder/LCD of cameras designed to accept this data. Different data standards are used by camera and battery manufacturers. PAGlink V-Mount batteries automatically adjust the data output standard to support SMB (Sony) and I C (IDX).
  • Page 12 6. Run-Time, Capacity & Data PAG Numeric Display Data Output Data stored in the battery’s microprocessor can be revealed using the battery display. Release to see 1st Press display button Press & hold for Press x3without Press & hold for ...which appears in...
  • Page 13 6. Run-Time, Capacity & Data PAG 5-Light Display Data Output 1. Percentage State of Charge Data stored in the battery’s microprocessor can be revealed using the battery display. The display lights indicate numbers 0-9 in the following way: Release to select Press &...
  • Page 14 6. Run-Time, Capacity & Data 3. Number of Cycles (Charge/Discharge) 5. Reset Function Press x4 without Press & hold to perform Press x2 without holding Press & hold to see ...this indicates 6. holding to select reset & do not release to select 3rd menu item: number of cycles.

  • Page 15: Battery Protection Features

    A thermal fuse is incorporated within the battery construction as a ‘backstop’ protection device, and this cannot be reset. In the unlikely event of this fuse operating, please contact PAG or your dealer.

  • Page 16: Paglink Features

    8. PAGlink Features Linking Batteries: Align the V-Mount connectors and push the battery down until you To release the battery, hold down the release button (1) and slide the hear a click, indicating that the lock is engaged. battery up (2).
  • Page 17 8. PAGlink Features PAGlink V-Mount Terminals: Base Terminals Front Terminals Rear PAGlink batteries can be linked to combine their capacities, for Terminals example, two 96Wh batteries provide 192Wh, and 3 offer 288Wh. Two 150Wh batteries offer 300Wh when linked. Batteries of any rated capacity, in any state of charge, can be linked for charge or discharge.
  • Page 18 8. PAGlink Features Linked batteries form a network which allows communication between batteries, ensuring that a safe protocol is followed under all circumstances. The PAGlink management system elects the battery with one or more connected to its front contacts to be the ‘master’ and ensures that this battery is always active (but not necessarily delivering current).

  • Page 19: Safety Information

    9. Safety Information 10.1 PLEASE READ THESE IMPORTANT SAFETY INSTRUCTIONS BEFORE Do not attempt to disassemble the battery. Refer faults to authorised USING THE BATTERY AND RETAIN THEM FOR FUTURE REFERENCE. service personnel. When used correctly, Lithium-Ion batteries are a rugged and safe Do not continue to use the battery if there is any change in the method of storing power.

  • Page 20: Servicing

    Unauthorised servicing invalidates the battery guarantee and its air safety status (IATA). If a fault develops, please contact a PAG service centre to receive a fault diagnosis. Batteries that require further analysis must be returned to your nearest PAG service centre. Li-Ion batteries are classified as dangerous goods and cannot be returned without prior contact.

  • Page 21: Recycling

    Expired batteries should be disposed of in accordance with the appropriate regulations or legislation. PAG offers a recycling service for its expired batteries in the UK. They can be returned to PAG Ltd. only by prior arrangement. They must be in a discharged state, and clearly marked ”FOR RECYCLING”.

  • Page 22: Guarantee

    In the event of failure of a product covered by this guarantee, PAG Limited will repair and calibrate equipment returned to an authorised Service Facility within the period of the guarantee, provided the guarantor’s examination discloses to its satisfaction the product was...

  • Page 23: Air Transport Regulations

    Test Report No. 102617072 state exemption has beenobtained (ie CAA/FAA operator). Copies of the test certificate and report can be obtained from PAG. Batteries DO NOT need to be discharged to 30% state of charge for transport as personal luggage, this is a requirement of cargo shipments only.
