(4) Microphone: Enable or Disable the microphone.
(5) Record: Record the current video on display.
(6) Window Fit: Display live view to fit the window size.
(7) Full Screen: Expand the current windows into maximum monitor size. Clicking
ESC button or right button on mouse to back to the normal view.
(8) Custom: Move the control bar to make preferred window size.

PTZ Control

CAUTION:
• Do not adjust zoom/focus in low light conditions or night
mode. It might cause erroneous focusing.

User Manual

Help the menu function. Click and pop-up the page about current menu description.
Used to adjust zoom/focus manually or one-push
focus automatically.
• Zoom: Adjusts camera image zoom in/out ratio
manually.
• Focus: Adjusts camera image focus manually.
• Push AF: When Push AF command is sent, camera
becomes Auto Focus mode to adjust focus position for
a while.
