Summary of Contents for Clarke CBAT1
- Page 1 12V LED BATTERY/ALTERNATOR TESTER MODEL NO: CBAT1 PART NO: 6260105 OPERATION & MAINTENANCE INSTRUCTIONS LS1113...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE product. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
-
Page 3: Safety Instructions
THOSE IN YOUR VEHICLE HANDBOOK VERY CAREFULLY BEFORE USING THE TESTER, KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE. Clarke International are not liable for any damages or consequences resulting from: • Connection and installation errors. • Damage to the device due to mechanical influences or voltage surges or any modification to the device. -
Page 4: Other Information
Do not open the case, there are no replaceable parts inside the product. If the product malfunctions, please consult your dealer. 10. Do not use the device while the vehicle is motion, the tester is not suitable for permanent installation in a motor vehicle. 11. -
Page 5: Display Identification
DISPLAY IDENTIFICATION Alternator Defect Indicator Battery Minimal Charge Indicator Alternator Good Indicator Battery OK Indicator Indicator Battery Fully Charged Clamps Indicator Battery Half Charged Indicator Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 6: Operation
OPERATION BATTERY CHECK Connect the red clamp to the positive (+) terminal on the car battery, then connect the black clamp to the negative (-) terminal. • The “Battery OK” LED (F) will light up if a voltage of at least 10V is detected. Remove the black clamp from the negative (-) terminal on the car battery... -
Page 7: Alternator Check
ALTERNATOR CHECK Connect the red clamp to the positive terminal (+) of the battery, then connect the black clamp to the negative terminal (-). • Check that the measuring device has a good connection to the battery Start the engine and turn on the headlights and radio. •... -
Page 8: Battery Charge Level
BATTERY CHARGE LEVEL With the engine not running, (ignition key in the first position), turn on the headlights of the vehicle for approximately 1 to 2 minutes. Turn off the headlights and remove the ignition key. Now disconnect the negative terminal (-) on the car battery. After 10 minutes connect the red clamp to the positive terminal (+) of the battery, then connect the black clamp to the negative terminal (-) of the battery. -
Page 9: Maintenance
MAINTENANCE CLEANING • Do not use any liquid cleaning product. • Do not use any inflammable cleaning product. • Do not submerge the device or spill any liquids over it. • If needed, clean the device with a light, damp, soft cloth. SPECIFICATION Product Description Alternator and battery tester... -
Page 10: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 11 AVAILABLE FROM YOUR CLARKE DEALER CEOBD ENGINE FAULT CODE CDM35 DIGITAL MULTIMETER READER • Access the vehicle’s engine • Protective shock resistant control unit to retrieve essential holster complete with probe emission based information, to holders and variable height read & clear diagnostic stand.
