The GNSS-750 is an active antenna designed to receive signals from the GPS, Galileo and GLONASS
satellites as well as L-Band signals. This antenna is designed to operate for GPS L1/L2/L2C/L5,
GLONASS L1/L2/L3 and L-Band frequency bands. The GNSS-750 is also designed to operate for Galileo
L1/E5a/E5b and E6 frequency bands and receives Compass B1/B2/B3. This guide provides the basic
information you need to install and begin using your new antenna.
Additional Equipment Required
The following equipment is required to set up the GNSS-750:
A sturdy pillar or mount with a 5/8" x 11 thread that extends between 3/8" and 7/8" (9 mm and 22 mm)
Coaxial cable with a male N connector
A device with an antenna input port that both receives the RF signal and provides 3.3 to 12.0 VDC to the
1
antenna
Accessories
Additional available accessories include the following:
A radome (NovAtel part number 01018195)
S
S
G
ITE
ELECTION
For optimal performance, select a site that meets the following conditions before installing:
An unobstructed as possible line-of-sight from horizon to horizon and at all bearings and elevation angles.
As far as possible from reflective objects, especially those that are above the antenna and any water bodies,
which can be a strong source of multi-path reflections.
If obstructions and reflective surfaces are within 30 m, ensure the site is as high as possible. Otherwise,
mount the antenna as low as possible.
Most NovAtel GNSS receivers provide the necessary power through their antenna RF connectors. Check
1.
the applicable receiver user manual for details.
UIDELINES
GNSS-750
ANTENNA GUIDE
OM-20000120
Rev 4
September 2012
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GNSS-750 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Novatel GNSS-750

  • Page 1 Rev 4 September 2012 The GNSS-750 is an active antenna designed to receive signals from the GPS, Galileo and GLONASS satellites as well as L-Band signals. This antenna is designed to operate for GPS L1/L2/L2C/L5, GLONASS L1/L2/L3 and L-Band frequency bands. The GNSS-750 is also designed to operate for Galileo L1/E5a/E5b and E6 frequency bands and receives Compass B1/B2/B3.
  • Page 2: Installing The Antenna

    NSTALLING THE NTENNA After a site has been selected, install the antenna as follows: 1. Verify that the thread on the mount does not extend more than 7/8" (22 mm) to ensure the antenna receptacle is not damaged when the mount is inserted. If it extends further than 7/8" (22 mm), add two jam nuts to shorten the exposed thread, ensuring the nuts are well tightened.
  • Page 3: Antenna Care

    NTENNA The GNSS-750 is designed to withstand the elements, including rain, snow, and dust. However, to ensure your antenna performs optimally, keep the top surface and the choke rings of the antenna clean and brush off any ice and snow. A radome is recommended. In addition, ensure the N connector remains clean and dry and replace the dust cap when a cable is not connected.
  • Page 4: Specifications

    PECIFICATIONS Upper:1525-1612 MHz 3 dB pass band (typical) Lower:1164-1301 MHz Out-of-band rejection (typical) 0 900 80 dB 900 1002.5 MHz 70 dB 1002.5 1062.5 MHz 50 dB 1062.5 1102.5 MHz 30 dB 1370 1465 MHz 30 dB 1410 1440 MHz 50 dB 1668 1718.5 MHz 30 dB...
  • Page 5 ECHANICAL RAWINGS All dimensions are in millimetres (mm) where 1 inch = 25.4 mm.
  • Page 6: Warranty Policy

    For absolute offset numbers and to download PCV (Phase Center offsets and Variations) tables, please visit the GEO++ Web site at www.geopp.com. When using the Web site mentioned above, look for the NovAtel listing of your antenna model and its hard- ware revision.
  • Page 7: Weee Notice

    NovAtel’s Customer Support. WEEE Notice If you purchased your GNSS-750 in Europe, please return it to your dealer or supplier at the end of its life. The objectives of the European Community's environment policy are, in particular, to preserve, protect and improve the quality of the environment, protect human health and utilise natural resources prudently and rationally.
  • Page 8: Questions Or Comments

    Questions or Comments If you have any questions or comments regarding your GNSS-750, please contact NovAtel Customer Support using one of methods provided below. E-mail: support@novatel.com Web: www.novatel.com Phone: 1-800-NOVATEL (International) or 403-295-4900 (U.S. & Canada) Fax: 403-295-4901 © Copyright 2012 NovAtel Inc. All rights reserved.
