Summary of Contents for AB IPBox Prismcube Ruby
-
Page 2: Main Features
Main Features • Twin Tuner HD Satellite Receiver • HDMI Output (up to 1080p) • DiSEqC 1.0, 1.1, 1.2, 1.3 (USALS) Compatible • Dolby Digital audio output (S/PDIF) • Extended EPG and program reservation on EPG • Open source media player XBMC with favorite addons •... -
Page 3: What's Included
What's included ? Power Adapter Easy Setup Guide HDMI cable HDD Bracket Screws Power Cable... -
Page 4: Front Panel
Front Panel Display Standby Displays the current menu and program information. Door open CI Module slot Smartcard reader slot One Smartcard slot is provided. -
Page 5: Rear Panel
Rear Panel Video/Audio Output Ethernet LNB INPUT 1/2 RS232 HDMI Connects to TV using a HDMI cable for both audio and video signals. S/PDIF Connects to a digital audio system Power Adapter Input using S/PDIF cable. -
Page 6: Remote Control
Remote Control STB Power TV Power Color Keys SOURCE • Red • Green Controls the outputs of TV. • Yellow • Blue XBMC Displays the XBMC Media Center. Displays the Electronic Program Guide (EPG) information if provided. Archive Displays the Archive window. Navigation Keys i (Information) Displays the channel and program... - Page 7 Remote Control QWERTY Unlock to use NOTE Two coin batteries (CR2032) are used in the remote control. The estimated battery lifetime is around 1year. To replace batteries use a screwdriver to pry open the lid.
-
Page 8: Connecting Cable
2. Connect ABIPBOX Prismcube Ruby to the TV One HDMI cable is included in the accessory box. Connect one end of the cable to the HDMI input of TV. Connect the other end to the HDMI output of ABIPBOX Prismcube Ruby. - Page 9 Connecting Cable 3. Power Up A power cord and an adapter are provided in the accessory box. Plug the round end of the adapter power cord into the power input. NOTE AC input condition • Nominal Voltage Range: 100 – 250 VAC •...
- Page 10 Run First Time Installation ABIPBOX Prismcube Ruby is a satellite (DVB-S2) twin tuner receiver. Please run the following installation steps for the basic system configurations. Step 1. Run First Installation - Press MENU and go to Installation. - Select First Installation and press OK.
- Page 11 Select Next and press OK to go to the next step. Step 4. Antenna & Satellite Setup ABIPBOX Prismcube Ruby has two satellite tuners. - Select Tuner 1 Control and choose from the below satellite signal control options : • Simple LNB / DiSEqC 1.0 / 1.1 / 1.2 / USALS.
- Page 12 Run First Time Installation Step 5. Channel Search Setup This menu allows you to configure the channel search options. - Channel Search : Yes / No - Satellite : All or installed satellite list (e.g. Astra, Hotbird) - Network Search : On / Off •...
- Page 13 Run First Time Installation Step 6. Channel Search You can see the progress of channel search. When the channel search is done, the search result will be displayed. - Press OK to complete the channel search. - Press BACK to go to the next step.
- Page 14 Run First Time Installation Step 7. Time & Date Setup You can either set the time/date manually or automatically. - Automatic – time/date is automatically set up according to the time/date information of the selected channel. - Manual – time/date is manually configured. Select Next to complete the First Installation.
- Page 15 A Guide to Request of GPLv2 based Software This product contains software whose rights holders license it on the terms of the GNU General Public License, version 2 (GPLv2). You can find the text of this license in its English original version in the manual for this product.
- Page 16 Now, your Prismcube Ruby is ready for your use! For more information about ABIPBOX Prismcube Ruby, go to "Help" from Main Menu.
- Page 17 XBMC Integrated Hybrid Linux Receiver www.prismcube.com...
