HomeWorks
®
Example Mounting
L-LV14
DIN Rail
Power Supply
(QSPS-DH-1-60)
|
4
Lutron
®
product specifications
QS MDU Processor
Wire Landing Boards
(QS-WLB)
369755a
(5) Ground
(4) Red L2 (Link 2) Power
(3) Red L1 (Link 1) Power
(2) Red P (Processor) Power
(1) Black COM (Common)
24/7 Technical Support—800.523.9466
01.24.13
