HomeWorks
®
The HomeWorks
 QS MDU processor provides
®
control and communication to HomeWorks
system components.
The Ethernet links allow communication to the
HomeWorks
 QS software, integration with third
®
party systems and control from the LutronR Home
Control+ mobile device application.
The processor is typically powered from the
QSPS-DH-1-60 power supply.
The HomeWorks
 QS MDU processor can
®
be installed in a HQ-LV21, L-LV21 or L-LV14
enclosure.
Processor Capabilities
The HomeWorks
 QS MDU processor has 2
®
links that are preconfigured as HomeWorks
Wired Link and HomeWorks
processor has a capacity of 50 devices/50 zones
maxiumum, shared between the two links. Refer to
HomeWorks
QS MDU System Architecture for a
®
list of devices for each link type.
www.lutron.com
QS MDU Processor
 QS
®
QS
®
QS RF Link. The
®
369755a

Model Number

HQP6-MDU
HomeWorks
01.24.13
 QS MDU Processor
®
|
Lutron
1
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the QS HQP6-MDU and is the answer not in the manual?

Questions and answers

Related Manuals for Homeworks QS HQP6-MDU

Summary of Contents for Homeworks QS HQP6-MDU

  • Page 1: Model Number

    HQ-LV21, L-LV21 or L-LV14 enclosure. Processor Capabilities The HomeWorks  QS MDU processor has 2 ® links that are preconfigured as HomeWorks ® Wired Link and HomeWorks QS RF Link. The ® processor has a capacity of 50 devices/50 zones maxiumum, shared between the two links.

  • Page 2: Specifications

    Low-Voltage Power 18 AWG (0.75 mm Wire Type Ethernet, RS485 (QS, RF, Power Panel) Communications Total link capacity between the HomeWorks  QS Wired Device Link and the Link Capacities ® HomeWorks  QS RF Link cannot exceed 50 devices / 50 zones.
  • Page 3 369755a 01.24.13 HomeWorks QS MDU Processor ® Dimensions Dimensions shown as: in (mm) Front View Side View 4.27 (108) 5.26 (134) 6.0 (125) 1.06 (26.9) www.lutron.com Lutron ®...

  • Page 4: Product Specifications

    369755a 01.24.13 HomeWorks QS MDU Processor ® Example Mounting (5) Ground (4) Red L2 (Link 2) Power (3) Red L1 (Link 1) Power (2) Red P (Processor) Power (1) Black COM (Common) Wire Landing Boards (QS-WLB) L-LV14 DIN Rail...
  • Page 5 369755a 01.24.13 HomeWorks QS MDU Processor ® Wiring Diagrams—Networking Standard Networking: Connection using an Ethernet hub/switch/router 3rd Party Integration Device (not supplied by Lutron) Ethernet Router Laptop PC Ethernet cable: Cat5/Cat5e 328 ft (100 m) maximum per home run HomeWorksR QS...
  • Page 6 Max 2A combined Draw from processor when powering both links from the same power supply Total link capacity between the HomeWorks  QS Wired Device Link and the HomeWorks  QS RF ® ® Link cannot exceed 50 devices / 50 zones.
  • Page 7 369755a 01.24.13 HomeWorks QS MDU Processor ® Wiring Diagrams—HomeWorks  QS RF Link ® HomeworksR QS Processor HomeworksR QS RF Link * HomeworksR QS Hybrid Repeater HomeworksR QS HQP6-MDU RF Link * HomeworksR QS RF Link * 30 ft (9 m)
  • Page 8 369755a 01.24.13 HomeWorks QS MDU Processor ® Wiring Diagrams—HomeWorks  QS Wired QS Link ® with Shades / Draperies (Controllable Window Solutions) L(+) N(-) 120 - 240 V 24 V Input / Entrada / Entrée Output / Salida / Sortie QSPS-DH-1-60 22.5 - 25 V...
