360 B A N D IT

™

I N S T A L L A T I O N I N S T R U C T I O N S

K I N Z E 3 0 0 0 M O D E L S

• • •

•••

3 6 0 Y I E L D C E N T E R . C O M

F O R Q U E S T I O N S P L E A S E C O N T A C T O U R

P R O D U C T S U P P O R T T E A M A T 3 0 9 - 3 0 0 - 3 1 2 0

1 . 3 . 2 0 • V 5

Table of Contents

Need help?

Do you have a question about the BANDIT KINZE 3000 and is the answer not in the manual?

Page 1 P R O D U C T S U P P O R T T E A M A T 3 0 9 - 3 0 0 - 3 1 2 0 1 . 3 . 2 0 • V 5 All trademarks are the property of 360 Yield Center, its affiliates and/or its licensors. ©2019 360 Yield Center. All rights reserved.
Page 2 3 can be discarded but the bushings 4 need to be Remove spring from closing wheel arm stop and set closing kept. wheel arm stop to the side. NOTE: Retain closing wheel arm stop in a safe location for installation of closing system without 360 BANDIT. PAGE 2...
Page 3 INSTALLATION INSTRUCTIONS KINZE 3000 STEP 3 STEP 4 STEP 5 INSTALL ROCK GUARD INSTALL BANDIT ARM ASSEMBLY INSTALL EXTENSION BRACKET Slide the BANDIT arm assembly over the extension Align holes in extension bracket with the holes on the Attach the rock guard 8 to the underside of the extention bracket , ensuring BANDIT arms are facing in the...
Page 4 INSTALLATION INSTRUCTIONS KINZE 3000 STEP 6 STEP 7 STEP 8 INSTALL SUPPORT STRAP REINSTALL CLOSING SYSTEM PREPARE HOSE GUIDES 21 21 Remove the bolt on the bottom of the depth adjustment Attach the tensioning spring on the closing system to the Using side-cutters, cut the two hose guides apart assembly and discard.
Page 5 Slide bolt of the disk assembly into the lower hole on the Attach the plumbing assembly to each of the hoses coming (not included) in the plumbing to each row prior to the 360 bandit , aligning the ear tab...
