ASROCK IMB-184-PY Settings Manual

*15G06M009001AK*
P/ N: 15G06M009001AK V1.1
IMB-184-PY
IMB-184
The terms HDMI™ and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
1 : 2-pin UPS Module Power Input
Connector
2 : PS2 Keyboard/Mouse Header
Signal Signal Signal
PIN PIN PIN
Name Name Name
+5V
8 GND 6 GND 4
STANDBY
7 MSCLK 5 MSDATA 3 KBDATA
3 : 4-pin ATX Power Input/Output Connector
4 : USB2.0 Headers (USB4_5, USB8_9)
DUMMY
GND GND
+A
+B
-B -A
SATA3_1
USB_PWR USB_PWR
1
5 : SATA3 Connectors
(SATA3_1, SATA3_2)
SATA3_2
6 : Digital Input / Output Pin Header
PIN Signal Name PIN Signal Name
10 GND 9 JGPIO_PWR
8 SIO_GP23 7 SIO_GP27
6 SIO_GP22 5 SIO_GP26
4 SIO_GP21 3 SIO_GP25
2 SIO_GP20 1 SIO_GP24
7 : SATA Power Output Connector
8 : VCCM Power Selection
Short: +1.36V
Open: Auto
Jumpers and headers setting guide
1 2 3
41
DC_JACK1
UPS_IN1
USB 3.0
INT_DC1
40
T: USB0
B: USB1
39
38
37
36
AMP_CTL1
1
1
BIOS
35
Chip
34
33
LAN1
32
USB 2.0
31
T: USB2
B: USB3
30
1
TPM1
29
Mic In
28
1
CLRCMOS1
1
SPEAKER1
27 Line Out 1
HD_AUDIO1
26
25
DMIC1
HDMI_SPDIF1
1
1
24 23
9 : Digital Input / Output Power Selection
(JGPIO_PWR) (JGPIO_PWR1)
1-2: +12V
2-3: +5V
1
COM1, 2, 3, 4 Headers
10 : COM1
Signal
PIN
Name
11 : COM2
+5V
2
12 : COM3
STANDBY
1 KBCLK
13 : COM4
Signal
PIN PIN
Name
10 +12V 8
9 +5V 7
* This motherboard supports RS232/422/485 on COM1 port. Please
refer to below table for the pin definition. In addition, COM1 port
(RS232/422/485) can be adjusted in BIOS setup utility > Advanced
Screen > Super IO Configuration. You may refer to page 34 of our
user manual for details.
PIN
1
2
3
4
5
6
7
8
9
10
14 : System Panel Header
GND
PWRBTN#
PLED-
PLED+
4 5 6 7 8 9 10
SATA3_1
USB4_5 USB8_9 SATA_PWR1
SATA3_2
COM1
1
1
VCCM_SEL1 JGPIO_PWR1
1 1
CI2
1
1
JGPIO1
1
CHA_FAN1
PS2_KB_MS1
CI1
1
1
1
PWR_JP1
JGPIO_SET1
AUDIO
CODEC
BUZZ1
CPU_FAN1
PCIE1
22
2
1
Signal Signal Signal Signal
PIN PIN PIN
Name Name Name Name
CCTS# 6 DDSR# 4 DDTR# 2 RRXD
RRTS# 5 GND 3 TTXD 1 DDCD#
COM1 Port Pin Definition
RS232 RS422 RS485
DCD TX- RTX-
RXD RX+ N/A
TXD TX+ RTX+
DTR RX- N/A
GND GND GND
DSR N/A N/A
RTS N/A N/A
CTS N/A N/A
+5V +5V +5V
+12V +12V +12V
GND
RESET#
GND
HDLED-
HDLED+
1
11 12 13 14
PANEL1
1
1 1 1 1
COM2 COM3 COM4
1
1
1
1
1
CS1
1
Industrial
21
15 : LVDS Panel Connector
PIN Signal Name PIN Signal Name
2 LCD_VCC 1 LCD_VCC
4 LDDC_CLK 3 +3.3V
6 LVDS_A_DATA0# 5 LDDC_DATA
8 GND 7 LVDS_A_DATA0
10 LVDS_A_DATA1 9 LVDS_A_DATA1#
12 LVDS_A_DATA2# 11 GND
14 GND 13 LVDS_A_DATA2
16 LVDS_A_DATA3 15 LVDS_A_DATA3#
18 LVDS_A_CLK# 17 GND
20 GND 19 LVDS_A_CLK
22 LVDS_B_DATA0 21 LVDS_B_DATA0#
24 LVDS_B_DATA1# 23 GND
26 GND 25 LVDS_B_DATA1
28 LVDS_B_DATA2 27 LVDS_B_DATA2#
30 LVDS_B_DATA3# 29 DPLVDD_EN
32 GND 31 LVDS_B_DATA3
34 LVDS_B_CLK 33 LVDS_B_CLK#
36 CON_LBKLT_EN 35 GND
38 LCD_BLT_VCC 37 CON_LBKLT_CTL
40 LCD_BLT_VCC 39 LCD_BLT_VCC
16 : Panel Power Selection (PNL_PWR1)
Signal Signal
PIN PIN
Name Name
6 NC 5 +5V
4 +12V 3 LCD_VCC
2 NC 1 +3.3V
17 : BLT_CTL1
PIN Signal Name
1 CON_LBKLT_EN
2 CON_LBKLT_CTL
3 LCD_BLT_VCC
4 LCD_BLT_VCC
5 GND
6 GND
7 GPIO_BLT_UP
8 GPIO_BLT_DW
15
16
17
18
19
20
2 1
40 39
1
1
