Jaz Ethernet Ferrite Installation
Overview
A ferrite is provided with your JAZ-E Ethernet module to be used in the event that you experience
interference with any electronic devices.
Connecting the Ferrite to the Jaz Ethernet Cable
►
Procedure
1. Find the Ethernet cable and the ferrite that you received in your Jaz package.
2. Open the ferrite.
3. Place the ferrite on the Ethernet cable as close to the connector for the computer as possible.
4. Loop the Ethernet cable through the ferrite twice.
100-4000-028-01-201510
1
