Yamabiko Echo SRM-2620ES Service Manual
  1. Manuals
  2. Brands
  3. Yamabiko Manuals
  4. Brush Cutter
  5. Echo SRM-2620ES
  6. Service manual

Yamabiko Echo SRM-2620ES Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SRM-2620ES
ECHO:
SRM-2620TES
T262XS C262S
shindaiwa:
T262TXS C262TS
(Serial number: 37000001 and after)
Ref. No. 402-43
Copyright C 2018 YAMABIKO Corporation All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Echo SRM-2620ES and is the answer not in the manual?

Questions and answers

Summary of Contents for Yamabiko Echo SRM-2620ES

  • Page 1 SRM-2620ES ECHO: SRM-2620TES T262XS C262S shindaiwa: T262TXS C262TS (Serial number: 37000001 and after) Ref. No. 402-43 Copyright C 2018 YAMABIKO Corporation All rights reserved.
  • Page 2 INTRODUCTION This service manual contains information for service and maintenance of ECHO TRIMMER / B R U S H C U T T E R , m o d e l s S R M -2620E S , SRM-2620TES, shindaiwa T262XS, C262S, T262TXS and C262TS.

  • Page 3: Table Of Contents

    SRM-2620ES, SRM-2620TES T262XS, C262S TABLE OF CONTENTS T262TXS, C262TS Page Page 1 SERVICE INFORMATION ........2 Testing carburetor ...........34 Specifi cations ...........2 Inspecting crankcase pulse passage .....35 Technical data ..........3 Inspecting metering lever height ....35 Torque limits .............5 Inspecting inlet needle valve ......36 Special repairing materials .......5 4-10 Inspecting diaphragm and others ....36 Service limits ............6...

  • Page 4: Service Information

    497 (19.6) Dry weight* kg (lb) 6.0 (13.3) 6.2 (13.7) 6.1 (13.5) 6.4 (14.3) Engine Type YAMABIKO, air-cooled, two-stroke, single cylinder Rotation Anticlockwise as viewed from the output end Displacement 25.4 (1.550) Bore mm (in) 34.0 (1.339) Stroke mm (in) 28.0 (1.102)

  • Page 5: Technical Data

    SRM-2620ES, SRM-2620TES T262XS, C262S SERVICE INFORMATION T262TXS, C262TS 1-2 Technical data Engine Compression pressure MPa (kgf/cm ) (psi) 0.97 (9.8) (140) Clutch engagement speed r/min 4,100 † Engagement Minimum r/min 3,800 Ignition system Spark plug gap mm(in) 0.6 - 0.7 (0.024 - 0.028) Spark test Tester gap w/ spark plug mm(in)
  • Page 6 SRM-2620ES, SRM-2620TES T262XS, C262S SERVICE INFORMATION T262TXS, C262TS 1-2 Technical data (continued) SRM-2620ES SRM-2620TES Model T262XS, C262S T262TXS, C262TS Carburettor adjustment Nylon line cutter Cutting head preparation Line length (w/o shield)* 190 mm 285 mm 1) Initial setting H mixture needle turn out L mixture needle turn out...

  • Page 7: Torque Limits

    SRM-2620ES, SRM-2620TES T262XS, C262S SERVICE INFORMATION T262TXS, C262TS 1-3 Torque limits Descriptions Size kgf•cm N•m in•lbf Starter system Starter pawl assembly 70 - 110 7 - 11 60 - 95 Starter case 40 - 60 4 - 6 32 - 55 Ignition system Magneto rotor (Flywheel) 160 - 200 16 - 20...

  • Page 8: Service Limits

    SRM-2620ES, SRM-2620TES T262XS, C262S SERVICE INFORMATION T262TXS, C262TS 1-5 Service limits 5K243 5K228 5K229 5K230 5K231 5K016 5K042 5K244 5K219 5K171 5K232 Description mm (in) A Cylinder bore When plating is worn and aluminum can be seen B Piston outer diameter Min.

  • Page 9: Special Tools

    SRM-2620ES, SRM-2620TES T262XS, C262S SERVICE INFORMATION T262TXS, C262TS 1-6 Special tools Part Number Description Reference G310-000050 Tachometer PET-304 Measuring engine speed to adjust carburettor X602-000340 Torx wrench (T27) Removing and installing bolt Y089-000094 Carburettor adjustment tool Adjusting carburettor A131-000160 Pressure connector Checking crankcase and cylinder leakages 897719-02830 Piston holder Making piston steady to remove and install piston/ring...

  • Page 10: Starter System

    SRM-2620ES, SRM-2620TES T262XS, C262S STARTER SYSTEM T262TXS, C262TS 2 STARTER SYSTEM (A) Starter case (B) Starter grip (C) Rope guide (D) Rewind spring (d) End of rewind spring (E) Rope reel (F) Power spring (f) Top end hook of power spring (G) Pawl catcher (H) Starter pawl (J) Spring...

  • Page 11: Disassembling Starter Assembly

    SRM-2620ES, SRM-2620TES T262XS, C262S STARTER SYSTEM T262TXS, C262TS 2-1 Disassembling starter assembly 1. Remove bolts (A) and muffl er cover (B). 2. Remove bolts (C) and cylinder cover (D). 3. Remove bolts (E), washers (F) and bolt (K) un- der fuel tank. Remove fuel tank guard (G) and fuel tank (T).

  • Page 12: Replacing Starter Rope

    SRM-2620ES, SRM-2620TES T262XS, C262S STARTER SYSTEM T262TXS, C262TS 2-1 Disassembling starter assembly (continued) 5. Pull out starter rope about 30 cm (12 in) and hold rope reel (M) by hand. Loop excess rope in rope reel notch (m) as shown. 6.
  • Page 13 SRM-2620ES, SRM-2620TES T262XS, C262S STARTER SYSTEM T262TXS, C262TS 2-2 Replacing starter rope 1. Pull out knot (A) and clip (B). Untie knot (A). 2. Pull out knot (D) from rope reel (C). 3. When installing a new starter rope, singe both ends of the rope to prevent from fraying.

  • Page 14: Replacing Rope Guide

    SRM-2620ES, SRM-2620TES T262XS, C262S STARTER SYSTEM T262TXS, C262TS 2-3 Replacing rope guide If rope guide is worn out or damaged, replace it as follows: 1. Remove or break rope guide by prying from starter case with a blade screwdriver. 2. Push out remaining guide from case. 3.

  • Page 15: Assembling Starter

    SRM-2620ES, SRM-2620TES T262XS, C262S STARTER SYSTEM T262TXS, C262TS 2-4 Installing rewind spring (continued) Rewind spring supplied as spare part is shipped in temporary retainer. To install new spring wound in retainer: 1) Align outer hook of spring in retainer with the holder (c) of starter case.
  • Page 16 SRM-2620ES, SRM-2620TES T262XS, C262S STARTER SYSTEM T262TXS, C262TS 2-5 Assembling starter (continued) 4. Install pawl catcher, assembling power spring hook (c2) into hole (e) of pawl catcher (E). 5. Fasten tapping screw (F) on starter post. 6. Pull out starter rope inside starter case. Ro- tate rope reel counterclockwise several turns with starter rope hooked at notch (a2) as shown.

  • Page 17: Replacing Starter Pawl

    SRM-2620ES, SRM-2620TES T262XS, C262S STARTER SYSTEM T262TXS, C262TS 2-6 Replacing starter pawl 1. Remove starter assembly, and check starter pawl (A) and pawl spring (B). Replace them if de- fective. 2. Clean dirt around spark plug, and remove spark plug. 3.
  • Page 18 SRM-2620ES, SRM-2620TES T262XS, C262S STARTER SYSTEM T262TXS, C262TS 2-6 Replacing starter pawl (continued) NOTE: Insert rib (h) of starter case to gap (f) be- tween crankacse and dust cover. Insert rib (j1) of starter case to hole (g1) of crankacse. Insert rib (j2) of starter case to hole (g2) of crankacse as shown.

  • Page 19: Ignition System

    SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3 IGNITION SYSTEM (A) Flywheel (B) Ignition coil (C) Spark plug (D) Spark plug cap coil (E) Spark plug cap (F) Ignition lead set (G) Grommet (H) Insulator tube (J) Connector 3-1 Troubleshooting guide Start Remedy Inspect...

  • Page 20: Testing Spark

    SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3-2 Testing spark 1. Remove spark plug cap from spark plug. 2. Connect spark tester 897800-79931 (A) to high tension lead and connect tester lead (B) on spark plug. 3. Screw in adjuster (a1) until the needle tips con- tact.

  • Page 21: Inspecting Ignition Switch

    SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3-4 Inspecting ignition switch 1. Disconnect primary lead coupler (A). 2. Disconnect ground lead coupler (B). 3. Connect one probe of Ohm-meter or multi- meter to primary lead (C) of ignition switch side as shown.

  • Page 22: Replacing Ignition Switch

    SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3-5 Replacing ignition switch For SRM-2620ES, SRM-2620TES, T262XS and T262TXS (L handle) 1. Remove screws (A) and remove rear handle grip half (B) from drive shaft housing. 2. Remove screws (C) from brackets (O) and re- move another rear handle grip half (D) from drive shaft housing.
  • Page 23 SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3-5 Replacing ignition switch (continued) 9. Route leads behind ignition switch (L), and then install ignition switch to rear handle grip half. Route leads through grooves and ribs (R) of rear handle grip half as shown. 10.
  • Page 24 SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3-5 Replacing ignition switch (continued) For SRM-2620ES, SRM-2620TES, C262XS and C262TXS (U handle) 1. Separate right-hand grip. Disconnect primary lead coupler and ground lead coupler (refer to “3-4 Inspecting ignition switch”). Disconnect throttle cable from carburetor.

  • Page 25: Inspecting Ignition Coil Resistance

    SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3-5 Replacing ignition switch (continued) 12. Seat square nut (G) in dent of handle grip and push in corrugated tube (F) to the grip two or three grooves from tube end. 13. Put together both grip halves. 14.

  • Page 26: Replacing Spark Plug Cap And Coil

    SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3-7 Replacing spark plug cap and coil 1. Disconnect spark plug cap (A) from spark plug. 2. Apply some oil in spark plug cap (A) for easy re- moval from high tension lead (B). 3.

  • Page 27: Setting Pole Shoe Air Gaps

    SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3-9 Setting pole shoe air gaps 1. Insert Module air gap gauge: 91004 (A) or 0.3 - 0.4 mm (0.012 - 0.016 in) thick feeler gauge be- tween fl ywheel and ignition coil shoes. 2.
  • Page 28 SRM-2620ES, SRM-2620TES T262XS, C262S IGNITION SYSTEM T262TXS, C262TS 3-10 Inspecting fl ywheel and key (continued) 6. Remove fl ange nut (G) on fl ywheel (H) using 13 mm (0.51 in) box wrench (B) or similar tool. 7. Set puller Y089-000111 (J) on fl ywheel (H) as shown.

  • Page 29: Fuel System

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4 FUEL SYSTEM ( A ) Fuel tank ( B ) Fuel cap ( C ) Fuel strainer ( D ) Fuel line grommet ( E ) Fuel line ( F ) Tank vent line ( G ) Fuel return line ( H ) Tank vent ( J ) Carburetor...

  • Page 30: Cleaning Air Fi Lter

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-1 Cleaning air fi lter 1. Close choke shutter and remove air cleaner cover and air fi lter. Outside 2. Clean air cleaner cover and air fi lter with com- pressed air or wash air fi lter in a suitable cleaning Engine side solvent.

  • Page 31: Inspecting Fuel Tank And Tank Vent

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-3 Inspecting fuel tank and tank vent 1. Remove air cleaner cover. Disconnect black fuel line from carburetor and connect pressure tester 897803-30133 (A) to fuel line with joint pipe V186- 000150 (B). 2.

  • Page 32: Replacing Fuel Line, Fuel Return Line, Tank Vent Line And Grommet

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-4 Replacing fuel line, fuel return line, tank vent line and grommet 1. Disconnect fuel line (A) and fuel return line (B) from carburetor. 2. Remove fuel line grommet (D) from fuel tank, together with fuel line (A), fuel return line (B) and tank vent line (C).
  • Page 33 SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-4 Replacing fuel line, fuel return line, tank vent line and grommet (continued) 5. Set clip (F) on fuel line (E) and connect fuel strainer (K) as shown. 6. Connect fuel line (A) on connector pipe (M). 7.

  • Page 34: Adjusting Carburetor

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-5 Adjusting carburetor 4-5-1 General adjusting rules A. Before adjustment, check the following items 1. Correct spark plug must be clean and properly gapped. 2. Air fi lter element must be clean and properly installed. 3.

  • Page 35: Adjusting Carburetor

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-5 Adjusting carburetor (continued) 4-5-3 Adjusting carburetor 1. Start and warm engine for 180 seconds alternat- ing RPM between idle for 10 seconds and WOT for 50 seconds. 2. Adjust L mixture needle (B) to reach maximum idle speed using D-shaped tool(A).

  • Page 36: Testing Carburetor

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-6 Testing carburetor 1. Remove air cleaner cover. Push purge bulb sev- eral times to fi ll and wet fuel pump circuit with fuel. 2. Pull off black fuel line (A) from carburetor and connect pressure tester 897803-30133 (C) to fuel fi...

  • Page 37: Inspecting Crankcase Pulse Passage

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-7 Inspecting crankcase pulse passage 1. Remove carburetor and insulator plate boot (B), and drop a little oil in pulse hole (A) on intake bel- lows. 2. Remove spark plug and pull starter grip several times.

  • Page 38: Inspecting Inlet Needle Valve

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-9 Inspecting inlet needle valve 1. Remove metering lever (A) and pivot pin. Re- move spring (B) and inlet needle valve (C). 2. Inspect inlet needle valve if worn or sticky. Clean or replace as required.

  • Page 39: Replacing Throttle Cable And Control Parts

    SRM-2620ES, SRM-2620TES T262XS, C262S FUEL SYSTEM T262TXS, C262TS 4-11 Replacing throttle cable and control parts When throttle cable inner wire does not move smoothly, disconnect throttle cable from carburetor and apply lubricating oil inside the cable. If it is still hard to move, replace throttle cable. For SRM-2620ES, SRM-2620TES, T262XS and T262TXS (L handle) 1.

  • Page 40: Clutch System

    SRM-2620ES, SRM-2620TES T262XS, C262S CLUTCH SYSTEM T262TXS, C262TS 5 CLUTCH SYSTEM ( A ) Fan cover ( B ) Ball bearing ( C ) Retaining ring ( D ) Clutch drum ( E ) Wave washer ( F ) Clutch shoe ( G ) Washer ( H ) Spring ( J ) Fan cover protector...

  • Page 41: Removing Clutch Shoes And Springs

    SRM-2620ES, SRM-2620TES T262XS, C262S CLUTCH SYSTEM T262TXS, C262TS 5-1 Removing clutch shoes and springs 1. Remove muffler cover, engine cover and fan cover. 2. Install rope (A) into spark plug hole by hand, to stop crankshaft rotation. NOTE: Do not use power tool. Otherwise, piston damage may occur.

  • Page 42: Removing Clutch Drum

    SRM-2620ES, SRM-2620TES T262XS, C262S CLUTCH SYSTEM T262TXS, C262TS 5-3 Removing clutch drum 1. Remove muffl er cover, cylinder cover, fan cover protector and fan cover. 2. Remove retaining clip from main pipe holder (A). 3. Lightly tighten drive shaft housing holder bolt (B). 4.

  • Page 43: Removing Clutch Drum Bearings

    SRM-2620ES, SRM-2620TES T262XS, C262S CLUTCH SYSTEM T262TXS, C262TS 5-4 Removing clutch drum bearings 1. Remove retaining ring (A) from fan cover. 2. Remove two ball bearings (B) together from fan cover, using bearing tool 897701-14732 (C) as shown. 5-5 Installing bearings and clutch drum 1.

  • Page 44: Engine

    SRM-2620ES, SRM-2620TES T262XS, C262S ENGINE T262TXS, C262TS 6 ENGINE ( A ) Cylinder ( B ) Intake heat shield ( C ) Exhaust heat shield ( D ) Cylinder gasket ( E ) Piston ring ( F ) Piston ( G ) Needle bearing ( H ) Piston pin ( J ) Snap ring ( K ) Oil seal...

  • Page 45: Testing Cylinder Compression

    SRM-2620ES, SRM-2620TES T262XS, C262S ENGINE T262TXS, C262TS 6-1 Testing cylinder compression NOTE: Test cylinder compression when engine is cold. 1. Move ignition switch to STOP position. Then re- move spark plug. 2. Install compression gauge 91037 (A) with Adapter P021-051690 (B) in spark plug hole and tighten by hand.

  • Page 46: Inspecting Muffl Er And Exhaust Port

    SRM-2620ES, SRM-2620TES T262XS, C262S ENGINE T262TXS, C262TS 6-3 Inspecting muffl er and exhaust port 1. Remove muffl er cover and cylinder cover. 2. Remove muffl er. 3. Inspect cylinder exhaust port and clean exhaust port using wooden or plastic stick if carbon is found.

  • Page 47: Testing Crankcase And Cylinder Sealing

    SRM-2620ES, SRM-2620TES T262XS, C262S ENGINE T262TXS, C262TS 6-4 Testing crankcase and cylinder sealing 1. Remove cylinder cover, muffl er, air cleaner cov- er and carburetor. 2. Close intake port and crankcase pulse passage using pressure rubber plug 897826-16131 (A) and Bellows holder (B).

  • Page 48: Inspecting Piston And Piston Ring

    SRM-2620ES, SRM-2620TES T262XS, C262S ENGINE T262TXS, C262TS 6-6 Inspecting piston and piston ring 1. Inspect piston rings and replace them if broken or scored, or if it exceeds service limits (Refer to “1-5”). 2. Inspect piston crown, top land, ring groove and skirt.

  • Page 49: Inspecting Crankcase And Crankshaft

    SRM-2620ES, SRM-2620TES T262XS, C262S ENGINE T262TXS, C262TS 6-8 Inspecting crankcase and crankshaft 1. Remove three bolts securing crankcase. 2. Hold a crankcase half and tap crankshaft end using plastic hammer to separate the halves with a heat gun. 3. Hold the other crankcase half and tap the end of crankshaft to remove crankshaft with a heat gun.

  • Page 50: Replacing Ball Bearing

    SRM-2620ES, SRM-2620TES T262XS, C262S ENGINE T262TXS, C262TS 6-10 Replacing ball bearing 1. Check main ball bearing for smooth rotation, after disassembling crankshaft. If rough, replace it (them) with new one. 2. Pry oil seal from crankcase. 3. Remove main ball bearing from crankcase half using bearing tool 897701-14732 as follows.

  • Page 51: Installing Piston

    SRM-2620ES, SRM-2620TES T262XS, C262S ENGINE T262TXS, C262TS 6-12 Installing piston 1. Place piston over the small end of connecting rod, so that the arrow mark (A) on piston points to- ward muffl er. 2. Insert piston pin guide (B) stamped “8”, through piston and washers (C) in connecting rod as shown.

  • Page 52: Cutter Drive System

    SRM-2620ES, SRM-2620TES T262XS, C262S CUTTER DRIVE SYSTEM T262TXS, C262TS 7 CUTTER DRIVE SYSTEM on SRM-2620ES, C262S and T262XS ( A ) PTO (Driven) Shaft ( B ) Ball bearing ( C ) Retaining ring ( D ) Washer ( E ) Blade fi xture ( F ) Gear set ( G ) Cup plate ( H ) Gear case...
  • Page 53 SRM-2620ES, SRM-2620TES T262XS, C262S CUTTER DRIVE SYSTEM T262TXS, C262TS 7 CUTTER DRIVE SYSTEM on SRM-2620TES, C262TS and T262TXS ( A ) PTO (Driven) Shaft ( B ) Ball bearing ( C ) Retaining ring ( D ) Washer ( E ) Blade fi xture ( F ) Gear set ( G ) Cup plate ( H ) Gear case...

  • Page 54: Disassembling Gear Case

    SRM-2620ES, SRM-2620TES T262XS, C262S CUTTER DRIVE SYSTEM T262TXS, C262TS 7-1 Disassembling gear case 1. Check gear case for cracks and PTO shaft for smooth rotation. Disassemble gear case as follows if defective. 2. Remove nylon line head from PTO shaft, and gear case (A) from drive shaft housing.

  • Page 55: Replacing Gears And Pto Shaft

    SRM-2620ES, SRM-2620TES T262XS, C262S CUTTER DRIVE SYSTEM T262TXS, C262TS 7-2 Replacing gears and PTO shaft NOTE : Replace drive gear (A), driven gear (B) and ball bearings (C) as a set. SRM-2620TES T262TS C262TXS 1. Remove retaining ring (D) using needle nose SRM-2620TES pliers.
  • Page 56 SRM-2620ES, SRM-2620TES T262XS, C262S CUTTER DRIVE SYSTEM T262TXS, C262TS 7-2 Replacing gears and PTO shaft (continued) For SRM-2620ES, C262S and T262XS 5. Install a new ball bearing (M) to the PTO shaft using oil seal tool 897714-24330 (F). 6. Install a new driven gear (N) to PTO shaft. 7.

  • Page 57: Assembling Gear Case

    SRM-2620ES, SRM-2620TES T262XS, C262S CUTTER DRIVE SYSTEM T262TXS, C262TS 7-3 Assembling gear case 1. Heat up the top of gear case with a heat gun as shown, then insert the assembled PTO shaft (A) into gear case until its bottom. WARNING DANGER When using a heat gun, put on gloves.

  • Page 58: Maintenance Guide

    SRM-2620ES, SRM-2620TES T262XS, C262S MAINTENANCE GUIDE T262TXS, C262TS 8 MAINTENANCE GUIDE 8-1 Service intervals Intervals Inspecting point Service Reference Daily 3 months 6 months Before use 100 hours 300 hours Screws and bolts * Retighten / Replace Air fi lter Inspect / Clean Choke system Inspect / Clean...

  • Page 59: Disassembly Chart

    SRM-2620ES, SRM-2620TES T262XS, C262S MAINTENANCE GUIDE T262TXS, C262TS 8-2 Disassembly chart Air cleaner Cylinder cover cover Starter Air filter assembly (4-1) cover (2-1) Ignition Clutch Clutch Pawl Carburetor Muffler assembly drum carrier coil (4-6) (6-3) (5-1) (2-6) (3-8) (5-3) Ball Flywheel Cylinder bearings...

  • Page 60: Troubleshooting Guide

    SRM-2620ES, SRM-2620TES T262XS, C262S MAINTENANCE GUIDE T262TXS, C262TS 8-3 Troubleshooting guide TROUBLE Engine does not crank. Engine does not start. Fuel leaks. Idling is not stable. Acceleration is poor. Engine stalls at high speed. Engine lacks power. Engine overheats. Engine misfires. Engine / others are extremely noisy.
  • Page 61 SRM-2620ES, SRM-2620TES T262XS, C262S MAINTENANCE GUIDE T262TXS, C262TS 8-3 Troubleshooting guide (continued) CHECKING REFERENCES Check first. Fuel system / Carburetor 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 Air filter Fuel cap / strainer Carburetor adjustment Carburetor leakage Fuel tank / vent / line...
  • Page 62 SRM-2620ES, SRM-2620TES T262XS, C262S MAINTENANCE GUIDE T262TXS, C262TS...
  • Page 63 SRM-2620ES, SRM-2620TES T262XS, C262S MEMORANDUM T262TXS, C262TS...
  • Page 64 Published by YAMABIKO Corp. Tokyo Japan 1802...
