Verizon Ellipsis™ Jetpack ® 4G LTE Mobile Hotspot
(Pantech MHS700L)

External Antenna Port Guide

The Verizon Ellipsis™ Jetpack ® 4G LTE Pantech MHS700L
Mobile Hotspot Has 2 Antenna Ports
Secondary
Primary
External Antenna Port
External Antenna Port

When Using Dual Antennas

When Using 1 Antenna

Connect an Antenna To Each Port
Connect Antenna To This Port
Warning:
The MHS700L external antenna ports can be fragile. Using excessive
force when connecting or disconnecting your adapter cable can damaged the
modem's internal antenna. To avoid damaging your modem - Be Gentle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ellipsis Jetpack Pantech MHS700L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Verizon Wireless Ellipsis Jetpack Pantech MHS700L

Summary of Contents for Verizon Wireless Ellipsis Jetpack Pantech MHS700L

  • Page 1 Page 1 of 3 Verizon Ellipsis™ Jetpack ® 4G LTE Mobile Hotspot (Pantech MHS700L) External Antenna Port Guide The Verizon Ellipsis™ Jetpack ® 4G LTE Pantech MHS700L Mobile Hotspot Has 2 Antenna Ports Secondary Primary External Antenna Port External Antenna Port When Using Dual Antennas When Using 1 Antenna Connect an Antenna To Each Port...
  • Page 2 Page 2 of 3 Verizon Ellipsis™ Jetpack ® 4G LTE Mobile Hotspot (Pantech MHS700L) Increase Speeds & Range An external antenna can improve performance when in fringe areas. To attach an external antenna first flip open the antenna cover(s). The Verizon Pantech MHS700L has two antenna ports for LTE MIMO capability. If you are only connecting a single antenna you should use Antenna Port - For convenient placement you can attach the antenna(s) to your laptop screen.
  • Page 3 Page 3 of 3 Verizon Ellipsis™ Jetpack ® 4G LTE Mobile Hotspot (Pantech MHS700L) Increase Speeds & Range An external antenna can improve performance when in fringe areas. To attach an external antenna first flip open the antenna cover(s). The Verizon Pantech MHS700L has two antenna ports for LTE MIMO capability. If you are only connecting a single antenna you should use Antenna Port - For convenient placement you can attach the antenna(s) to your laptop screen.
