Product description
Superheterodyne radio control devices, with the carrier frequency in the UHF band
controlled by saw resonator, for the remote control of electronic and electrical appli-
ances in conformity with the laws and standards in force.
The type of rolling code transmission signal makes it impossible to duplicate.
The system consists of 2 transmitter versions, one with a maximum of 4 channels and
the other with a maximum of 2 channels (mini transmitters).
The transmitter code can be inserted (memorised) either directly into the receiver or
via radio from the transmitter. The second possibility allows you to insert new trans-
mitters into an existing system without having to have the receiver on hand. This may
be carried out easily by the user without the help of the installer whilst still guaranteeing
the total secrecy of the code.
The user code is memorised under EEprom in the receiver which maintains the code
information even when faced with blackouts.
Transmitters
The transmitters are encoded in the factory and each transmitter has its own unique
code.
Caution!
If you keep a channel button pressed down for more than 30 seconds the transmitter
will automatically switch off.
The transmitters are available in 1,2 and 4 channel versions with the following codes:
TXR433A01 1 channel transmitter
TXR433A02 2 channel transmitter
TXR433A04 4 channel transmitter
TXR434A02 2 channel mini transmitter
Receivers
The receivers can be :
• a single channel slot-in receiver card to be inserted into an appliance which is designed
to receive it.
• a single channel box
RSM434F01-I 1 channel vertical slot-in receiver card 24Vac/dc
RSM434A01-I 1 channel vertical slot-in receiver card 24Vac/dc
RSM434B01-I 1 channel vertical slot-in receiver card 24Vac/dc
RSM434C01-I 1 channel vertical slot-in receiver card 24Vac/dc
RSM434D01-I 1 channel vertical slot-in receiver card 12Vac/dc
RSM434H01-I 1 channel vertical slot-in receiver card 12Vac/dc
RSD434A01-I 1 channel vertical slot-in receiver card 8-12V dc
CODE MEMORISING WITH THE PUSH BUTTON MEM IN THE RECEIVER:
For security, each time you carry out a new installation, you are advised to wipe the
entire memory
(max. 85 codes using the 93C66 memory module)
(max. 340 codes using the 93C86 memory module)
The user code and the relative channel functions are memorised or cancelled via radio
using the following procedure:
1) Press and hold down "P1," after 0.8 seconds the buzzer "B1" will sound continuously
2) Transmit the channel which is to be memorised,the buzzer "B1" will sound intermittently
To insert ulterior codes repeat points 1 and 2
If the code is not memorised it could be due to the following conditions:
- The code already exists in memory
- The memory is full (max. 85 codes using the 93C66 memory module or max 340 codes
using the 93C86 memory module). In this case the buzzer will sound intermittently
for 3 seconds each time the power is switched on.
TO CANCEL A CODE WITH THE PUSH BUTTON DEL IN THE RECEIVER:
1) Press and hold down "DEL", after 0.8 seconds buzzer B1 will sound intermittently
slowly
2) Transmit the code which is to be cancelled , once it has been cancelled, buzzer
"B1" will sound continuously
To cancel ulterior code repeat points 1 and 2.
TO CANCEL ALL MEMORISED CODES WITH THE PUSH BUTTON DEL IN THE
RECEIVER:
1) Press and hold down "DEL" at least for 8 seconds, then buzzer "B1" will sound slowly
and intermittently. At this point release "DEL" and press it again within 0.5 seconds,
hold it down for at least 10 seconds ( during this period buzzer " B1" will sound
intermittently and quickly ) as buzzer "B1" will sound continuously. Release the button
after completing the operation.
HOW TO INSERT A TRANSMITTER VIA RADIO WITHOUT ACCESSING THE RE-
CEIVER WHEN THE MEMORY IS EMPTY (First Installation)
The first transmitter to be inserted becomes the master transmitter for inserting other
transmitters
1) Press "P3" and the receiver will enter the memorising code. The buzzer will sound
continuously for 5 seconds.
2) Transmit the channel which is to be memorised within 5 seconds. Once the channel
is memorised the buzzer will sound intermittently.
Attention! When memory is empty do not give power to more than one receiver at a
time , because the above mentioned procedure activates all receivers
When the code has not been stored:
1) The code is already in memory.
Code Number:
RSM-RSD434-I
TELECO AUTOMATION SRL -
++39.0438.388511 FAX: ++39.0438.388536
TELEPHONE:
This document is the property of Teleco Automation SRL who reserve all reproduction and copying rights
DIGITAL RADIO CONTROL SYSTEM RS434
Series
RS433
Viale del Lavoro, 5 - 31014 Colle Umberto (TV) ITALY
2) The receiver memory is full (the Buzzer B1 will sound intermittently for 3 sec-
onds).
HOW TO INSERT AND ADDRESS A TRANSMITTER VIA RADIO WITHOUT ACCESS-
ING THE RECEIVER WHEN A TRANSMITTER IS ALREADY MEMORISED
1) Press the button "P3" (of an already memorised transmitter) . The buzzer will sound
continuously for 5 seconds.
2) Press the button of a channel already in the receiver memory (you have
activated the memory of the desired receiver) where you want to address the
new transmitter channel. The Buzzer B1 will stop sounding for 1 second and
will begin sounding for 5 seconds. Unless desired, do not use channels with
the centralised function to avoid storing the code in all receiver memories.
3) Transmit the channel which is to be memorised within 5 seconds. Once the channel
is memorised the buzzer will sound intermittently.
To insert ulterior functions repeat operations 1-2-3.
If the receiver memory is full, buzzer "B1" will sound intermittently.
TO CANCEL VIA RADIO A CODE THROUGH A TRANSMITTER ALREADY SET IN
THE MEMORY
1) Press "P3" for three times at regular intervals within 5 seconds, buzzer "B1" will
sound intermittently slowly.
2) Transmit the code which is to be cancelled within 5 seconds, once the code has
been cancelled buzzer "B1" will stop sounding.
To cancel ulterior codes repeat points 1 and 2
Antenna
The correct installation and connection of the antenna is fundamental in order to obtain
a good range for the installation.
Connect a 17 cm piece of wire to the antenna pole connection on the device.
As an alternative (and for better results) use a tuned antenna connected to the receiver
via a coaxial cable RG 58 (impedance 50 W) with a maximum length of 15 metres (mod.
ANT433).
TRANSMITTERS
- carrier frequency
- carrier frequency tolerance
- band width
- apparent radiated power
- apparent power harmonic producedes
- modulation
- signal modulation
- TXR433 series power supply
- TXR434 series power supply
- maximum power consumption
- operating temperature range
RECEIVERS
- reception frequency
- local oscillation frequency
- local oscillation tolerance
- local oscillation emission
- intermediate frequency IF
- antenna impedance in input
- sensibility (finely tuned signal)
- power supply for slot-in receiver card
- maximum power consumption at rest
- maximum power consumption with activated relay 30 mA
- maximum commutable power at the relay
with resistive load:
load dc
load ac
maximum voltage
- excitation delay
- dropout delay
- operating temperature range
(F)
TELECOMMANDES DIGITALES
Description du produit
Les télécommandes superhétérodynes, dont la portée en bande HF est
contrôlée par un résonateur, sont utilisées pour la commande à
distance d'ouvre-portes électriques ou électroniques, et ceci en
respectant les normes de sécurité en vigueur.
Il est impossible de copier le signal rolling code émis.
Le système se compose de deux types d'émetteurs (un emetteur avec
max. 4 canaux, et un mini emetteur avec max. 2 canaux).
Le mode de programmation peut être activé soit directement dans le
récepteur, soit au moyen de l'émetteur. Cette seconde possibilité
permet de programmer de nouveaux émetteurs dans un système
existant au moyen d'un émetteur, p.e. quand le récepteur est
difficilement accessible.
L'utilisateur peut faire cela facilement sans l'aide de l'installateur.
Le code de l'émetteur est programmé dans la mémoire Eeprom du
récepteur, où les données sont maintenues, même lors d'une
Model number
1
433.92 MHz
±75 KHz
>25 KHz
-10÷-7dBm (100-200µW)
<-54 dBm (<4nW)
AM/ASK
PCM, 1.3 ms/bit
12V (Alkaline battery GP23A)
3V (Lithium battery CR2032)
25 mA
- 10° +55°C
433,92 MHz
433,42 MHz
±75 KHz
<57dBm
500 KHz
50
1 µ V
12V ± 10%
14 mA
28W
60VA
48Vac
150 ms
150 ms
-20° + 55°C
SERIE RS 434
Draft
T141.01
Ω
Date
25-03-2004
