Thule Corsaire Instruction Manual

ANCHOR STRAP INSTRUCTION MANUAL
models
1.1 Preliminary steps
Please read the Infant Sling
manual prior to installing this
anchor strap.
First guide the
unfastened anchor strap through
that are at the bottom
towards the front, re-fasten the
anchor strap and
pull it very tight.
When viewed from the
inside of the trailer,
the anchor strap and
front of the vertical frame
tubes.
1.2 Lateral positioning
Start with the strap that is closest
to the trailer side at the front of the
Infant Sling.
Thread it down in front of the tel-
escopic tube.
The easiest way of getting the strap
tight is by pulling the end of the strap
downwards below the seat.
View from inside with seat lifted
for clarity.
C
at the bottom – the anchor strap is
pulled through this as well. Now once
again, in front of the telescopic tube,
pull it upwards again.
Then thread the second Infant Sling
front strap in front of the telescopic
tube, around the anchor strap and
again back up in front of the tel-
escopic tube.
Place the Infant Sling inside the
trailer as shown in the above picture.
Illustration A
Thread the end of the strap as shown
in the above illustration through the fas-
tener in the Infant Sling and gently pull
the strap tight.
Illustration A
Thread the end of the strap as shown
in the above illustration through the fas-
tener in the Infant Sling and gently pull
the strap tight.
11/12/2015
51100960
