- Page 1 USER + INSTALLATION √ Instructions Thule Omnistor 8000 EM motor 230V 3026xx Bring your life 5AP917-04 | 3380064400 thule.com 2021-11-15...
- Page 3 Markise - Bedienungsanleitung AWNING - USER INSTRUCTIONS Luifel - Gebruikershandleiding Store - Instructions d'utilisation Tenda - Istruzioni per l'uso Safety Toldo - Instrucciones de uso Markis - Användarmanual Markiisi - Käyttöohje Markise - Brugervejledning Markise - Brukerinstruksjoner Markiza - Instrukcja dla użytkownika USER WARNINGS &...
- Page 4 FOOT SUPPORT INSTALLATION Installation der Fußstütze / Installatie voetsteun / Installation du repose-pieds / Installazione del supporto del piede / Instalación del soporte para pies / Fotstödsinstallation / Jalkatuen asennus / Montering af fodstøtte / Fotstøttemontering / Instalacja wspornika stopy HAND CRANK SUPPORT INSTALLATION Installation der Handkurbelstütze / Installatie handzwengelsteun / Installation du repose-manivelle / Installazione del supporto della manovella manuale / Instalación del soporte de la manivela / Installation av handvevsstöd /...
- Page 5 POWER SUPPLY TOO HIGH (U > 250V) Spannungsversorgung zu hoch (U > 250 V) / Voedingsspanning te hoog (U > 250 V) / Alimentation électrique trop élevée (U >250 V) / Alimentazione troppo alta (U > 250 V) / Voltaje demasiado alto (U > 250 V) / Strömtillförsel för hög (U >...
- Page 6 USER USER 1 WARNINGS & INFO Instructions Safety 5AP917-04...
- Page 7 USER CLOSE THE AWNING OPTION 307916 5AP917-04...
-
Page 8: Remote Control System
USER STOP OPEN Remote Control system OPEN STOP OPEN STOP OPEN CLOSE STOP CLOSE OPEN STOP CLOSE STOP CLOSE STOP Switch system (optional) OPEN STOP CLOSE STOP OPEN CLOSE STOP CLOSE C L O S E S T O CLOSE STOP 5AP917-04 C L O S E... - Page 9 USER 2 OPEN OPEN STOP 5AP917-04...
- Page 10 USER 5AP917-04...
- Page 11 USER OPEN START 5AP917-04...
- Page 12 USER TENSION CLOSE 5AP917-04...
- Page 13 USER OPTION 307916 ® ® S S W W E E D D E E N N 5AP917-04...
- Page 14 USER 3 CLOSE LESS TENSION OPEN 5AP917-04...
- Page 15 USER 5AP917-04...
- Page 16 USER CLOSE START STOP 5AP917-04...
- Page 17 USER 5AP917-04...
- Page 18 USER START CLOSE 5AP917-04...
- Page 19 4 ACCESSORIES Thule Hold Down Side Strap Kit (307916) Thule 3 Support Leg (306778) Thule Wall Organizer (306924) / Shoe Organizer (306925) Thule Tension Rafter G2 (307313) ® ® S S W W E E D D E E N N ®...
- Page 20 USER Thule Rain Blocker G2 Thule Sun Blocker G2 Thule Panorama Thule Residence G3 Thule QuickFit 5AP917-04...
-
Page 21: Installation
INSTALLATION INSTALLATION 1 CONTENT AWNING x1 (x2) N° 4 4 x 21.2 mm 4.2 x 25 mm 4.2 x 25 mm 4.2 x 16 mm ALU-PLK DIN 125 DIN 7981 DIN 7982 DIN 7504 TX20 TX20 TX20 5AP917-04... - Page 22 INSTALLATION 105 mm 4.00 m 4.50 m 5.00 m 5.50 m 6.00 m 43.56 kg 46.76 kg 50.36 kg 53.96 kg 57.56 kg 2 TOOLS TX15 Ø 3.5 mm Ø 4.0 mm TX20 SIKA 221 5AP917-04...
-
Page 23: Awning Installation
INSTALLATION 3 AWNING INSTALLATION 5AP917-04... -
Page 24: Electrical Installation
INSTALLATION 4 ELECTRICAL INSTALLATION Control Box 230 V Remote Control Switch S1 Tubular Motor 230V-30Nm THULE TUBULAR MOTOR EM-230V THULE CONTROL BOX TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS Supply 230V AC / 50 Hz Supply 230 V AC / 50 Hz Rated Power... -
Page 25: Electrical Wiring Diagram
TO 8000 3 2 1 RA=Black TO 9200 N=Blue RA=Brown EA=Brown N=Blue EA=Black TO 9200 RA=Brown Thule Awning Control Box for TO 8000 & TO 9200 230V N=Blue EA=Black Thule Awning Control Box for TO 8000 & TO 9200 230V 5AP917-04... - Page 26 INSTALLATION Connect to Control Box Tubular Motor 230V-30Nm Dashboard Switch START (optional) Inverter Min. 300W Control Box Remote Control 5AP917-04...
- Page 27 MUSTA/SORT/SVART/ MUSTA/SORT/SVART/ EA=Black EA=Black 0.75 mm 0.75 mm CZARNY CZARNY Thule Awning Control Box for TO 8000 & TO 9200 230V Thule Awning Control Box for TO 8000 & TO 9200 230V GREEN/GRÜN/ GREEN/GRÜN/ GROEN/VERT/VERDE/ GROEN/VERT/VERDE/ VERDE/GRÖN/ VERDE/GRÖN/ 1.5 mm 1.5 mm...
- Page 28 ZWAR ZWAR N=Blue N=Blue NEGR NEGR EA=Black EA=Black MUST MUST CZAR CZAR Thule Awning Control Box for TO 8000 & T Thule Awning Control Box for TO 8000 & T GREE GREE GROE GROE VERD VERD VIHRE VIHRE N/ZIE N/ZIE...
- Page 29 INSTALLATION Check ! START OFF ACC OFF ACC START START START START OPEN OPEN OPEN OPEN CLOSE CLOSE CLOSE CLOSE OPEN NOT OPEN CLOSE CLOSE TRUE 5AP917-04...
- Page 30 INSTALLATION 5 FOOT SUPPORT INSTALLATION 12 cm 12 cm 12 cm 12 cm 5AP917-04...
- Page 31 INSTALLATION Ø 3.5 mm SIKA 221 Ø 4.0 mm TX20 5AP917-04...
- Page 32 INSTALLATION 5AP917-04...
- Page 33 INSTALLATION 6 HAND CRANK SUPPORT INSTALLATION TX20 7 REMOTE CONTROL SUPPORT INSTALLATION TX15 5AP917-04...
-
Page 34: Troubleshooting
INSTALLATION TROUBLESHOOTING 1 CHECK PRODUCT INFO Thule Omnistor 8000 306634 306634 306634 9200 WHI 230V 5.50M 31 9200 WHI 230V 5.50M 31 9200 WHI 230V 5.50M 31 Product number: 30xxxx ............308758 308758 306634 308758 Product description: 8000 WHI 230V 5.50M 31 8000 WHI 230V 5.50M 31... - Page 35 TROUBLE SHOOTING 2 WHAT IF THE AWNING DOESN'T WORK ? OPEN CLOSE ERROR Cause Solution CODE (beeps) ..Power supply too low (U < 200V) Check battery, inverter and electrical p 38 wiring..Power supply too high (U > 250V) Check battery, inverter and electrical p 39 wiring.
- Page 36 TROUBLE SHOOTING 3 WHICH MOTOR 230V IS USED IN THE AWNING ? WALL MOUNTING 8000 Thule Omnistor FABRIC ROLL UP DIRECTION Check electrical power connection to the motor: With the main power 230V OR With inverter (300W) to make 230V POWER OFF / WAIT 5 sec.
-
Page 37: Manual Override
TROUBLE SHOOTING 4 MANUAL OVERRIDE OPEN CLOSE 90° OPEN CLOSE 5AP917-04... - Page 38 TROUBLE SHOOTING 5 POWER SUPPLY TOO LOW (U < 200V) < 200 V OK ? OK ? OK ? OK ? OK ? OK ? OR / AND 230V 230V CAMPING INVERTER 5AP917-04...
- Page 39 TROUBLE SHOOTING 6 POWER SUPPLY TOO HIGH (U > 250V) > 250 V OK ? OK ? OK ? 230V OK ? OK ? OK ? OK ? OK ? 230V 230V 5AP917-04...
- Page 40 TROUBLE SHOOTING 7 IGNITION KEY (D+) IS ACTIVE START OFF ACC OFF ACC START START START START Motor temperature OPEN USE AWNING NOT OPEN CLOSE MOTOR IS NOT W > 4 min. CLOSE THERMAL PRO Motor temperature 8 THERMAL PROTECTION OF THE MOTOR Motor temperature Wait 15 minutes.
- Page 41 TROUBLE SHOOTING 9 REMOTE CONTROL IS BROKEN OR LOST No signal (battery) CLOSE CLOSE CLOSE CLOSE CR 2032 CLOSE ORDER New Remote Control CLOSE > Contact your dealer part 1500603579 5AP917-04...
- Page 42 TROUBLE SHOOTING 10 LIMIT SETTING (AWNING) N° ? CLOSE (TURN RIGHT) White Limit Hole LIMIT ADJUSTER Red Limit Hole LIMIT ADJUSTER 5AP917-04...
- Page 43 STOP CLOSE TROUBLE SHOOTING IN (Limit setting) - Awning does not close completely ! OPEN OPEN OPEN OPEN CLOSE CLOSE CLOSE CLOSE ± 20 cm OPEN OPEN OPEN OPEN CLOSE CLOSE CLOSE CLOSE OPEN OPEN STOP STOP CLOSE ± 30 cm OPEN OPEN STOP...
- Page 44 TROUBLE SHOOTING OUT (Limit setting) OPEN OPEN OPEN OPEN CLOSE CLOSE STOP CLOSE CLOSE OPEN STOP OPEN STOP ± 20 cm OPEN OPEN CLOSE CLOSE CLOSE STOP CLOSE STOP OK ? REPEAT OPEN STOP STEP A,B,C,D 5AP917-04...
- Page 45 TROUBLE SHOOTING STOP OPEN OPEN STOP STOP ± 20 cm STOP OPEN OPEN OPEN OPEN CLOSE CLOSE CLOSE CLOSE CLOSE STOP CLOSE STOP OPEN OPEN STOP STOP ± 30 cm CLOSE STOP CLOSE STOP 5AP917-04...
- Page 46 TROUBLE SHOOTING OK ? REPEAT OPEN STOP STEP A,B,C,D,E,F Example Smart Panel (Side) OPEN OPEN OPEN OPEN CLOSE CLOSE CLOSE CLOSE CLOSE STOP OPEN OPEN STOP STOP ± 20 cm CLOSE STOP CLOSE STOP 5AP917-04...
- Page 47 TROUBLE SHOOTING OK ? REPEAT OPEN STOP STEP A,B,C,D CLOSE STOP 5AP917-04...
- Page 48 TROUBLE SHOOTING 11 CONTACT DEALER Your Thule dealer details: The Thule dealer can place his contact details here Find your Thule dealer: www.thule.com 5AP917-04...
