Summary of Contents for Precaster LDM60
- Page 1 NEW BENCHMARK OF MEASURING LDM60 LASER DISTANCE METER OPERATION MANUAL...
- Page 2 Inside the Box 1. Laser Distance Meter x 1 2. Carrying case x 1 3. AAA Batteries x 2 4. Safety Strap x 1 5. Quickstart card x 1 Specification Model LDM60 Measuring Range 0.05m~60m Resolution 0.001m Accuracy ±1.5mm Measuring Speed 0.5 seconds...
- Page 3 LDM60 OPERATION MANUAL www.precaster.com.tw 7. The device support Bluetooth complies with part 15 of the FCC Rules. The operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 4 NEW BENCHMARK OF MEASURING Overview for device A. LCD B. Single measure / Tap and hold continuous measure C. Addition D. Subtraction / Tap and hold to change unit E. Clear / Power F. Area and volume (Area -> Volume -> Stake out ->...
- Page 5 LDM60 OPERATION MANUAL Battery Installation & Power Status 1. This unit is powered by 2 x AAA Batteries. 2. Remove battery lid and observing correct polarity before install batteries. 3. When the icon appears , it mean fully charged battery.
- Page 6 NEW BENCHMARK OF MEASURING · Area Measurement 1. Tap to start measurement. 2. Follow the instructions on the screen to measure the width and length. 3. You will get the result of area automatically. 4. You can click to add or subtract several volumes. ·...
- Page 7 LDM60 OPERATION MANUAL www.precaster.com.tw Indirectly Height Measurement (based on Pythagorean, to find out more introduction about Pythagorean, please refer to Wikipedia, entries Pythagorean theorem.) · Indirectly Height I (2 points) 1. Tap to enter [Indirectly height I]. 2. Follow the instructions on the screen to measure the length of hypotenuse(s) and base.
- Page 8 (shadow target) Service Support Please contact your local dealer or contact us through service email: [ support@precaster.com.tw ] for further assistance. PRECASTER ENTERPRISES CO., LTD. Add: No. 204, Sec. 2, Fu-Hsing Rd., Taichung, Taiwan Tel: 886-4-2262 1000. Fax: 886-4-2261 6565 Http://www.precaster.com.tw...
