Chapter 3 Installation Procedure

INSTALLATION PRECAUTIONS

Before connecting AC supplies to this equipment.
1) Ensure good airflow over the heatsink. Maintain clearance of 75mm above and below
controller. For safety maintain a clearance of 20mm at the sides of the controller.
2) Operating temperature range does not exceed 0 to +40øC.
3) Controller is used in a Pollution Degree 2 environment.
4) Avoid vibration.

MECHANICAL INSTALLATION

L1 POWER ON
L2 STALL TRIP
L3 OVERCURRENT
L4 PLL LOCK
L5 CURRENT LIMIT
514C
EUROTHERM
DRIVES
CAUTION
Before Switching ON Refer to the Manual for Installation and Safety,
Switch and Transformer Setting Information.
CAUTION
Risk of Electric Shock - More than One Disconnect Switch may be Required
to De-energise the Equipment Before Servicing
AVERTISSEMENT
Risque de decharge electrique. La coupure de plusieurs interrupteurs pout
etre necessaire avant utilisation - voir le schema
CAUTION
Compatible with Type B RCD Protection Devices Only
ON
1
1 2 3 4 5 6 7 8 9 10
SW2
Tens
FL1 FL2 F- F+
PRODUCT
514C/04
514C/08
514C/16
514C/32
514C Product Manual
P1
RAMP UP
P2
RAMP DOWN
P3
SPEED PROPORTIONAL
P4
SPEED INTEGRAL
P5
CURRENT LIMIT
P6
CURRENT PROPORTIONAL
P7
CURRENT INTEGRAL
P8
IR COMPENSATION
P9
P10
MAX SPEED CALIBRATION
P11
ZERO SPEED ADJUST
P12
ZERO SPEED THRESHOLD
SW1
SW3 SW4
Tenths
Unit
L2/N L1 A+
E
B
OVERALL
DIMENSIONS
A B
240mm 160mm 90mm 210mm 148mm
240mm 160mm 90mm 210mm 148mm
240mm 160mm 130mm 210mm 148mm
240mm 160mm 130mm 210mm 148mm
Setting up & Commissioning
G
A-
(measurement for 514C/04 and 08)
(measurement for 514C/16 and 32)
FIXING
CENTRES
C D E
C
C
SIZE SLOT DETAIL
F G
M6 15mm 7mm
M6 15mm 7mm
M6 15mm 7mm
M6 15mm 7mm
3-1
