Summary of Contents for Diamond GY60E
- Page 1 10/2005 Mod: GYROS 10E Production code: GY-INO10E-9841 The catering program...
- Page 2 MANUALE PER L’INSTALLAZIONE, L’USO E LA MANUTENZIONE DEI GYROS ELETTRICI INSTRUCTION FOR THE ASSEMBLY, USE AND MAINTENANCE OF ELECTRIC GYROS NOTICE POUR L'INSTALLATION, L' UTILISATION ET L'ENTRETIEN DES GYROS GEBRAUCHSANWEISUNG FÜR GYROS INSTRUCCIONES DE USO CALENTADORES DE GYROS...
- Page 3 COD. 9882 COD. 9849 COD. 9848 M. Cap. kg Mod. Cod. Volt Dimensions 230/1 400x450x590h GY-INO10E 9841 GY40E 9829 400/3+N 500x640x650h 20÷25 GY60E 9830 400/3+N 500x640x810h 30÷40 GY80E 9831 400/3+N 500x640x970h 40÷50 GY100E 9832 400/3+N 500x640x1150h 50÷60 GY20EIR 9882 230/1 400x500x600h 10÷15...
- Page 4 SERIE - MODELS - PRODUITS - GERÄTE - MODELOS Le producteur informe que les appareils sont: conformes aux Directives: 93/68 CEE 89/336 CEE 73/23 CEE conformes aux Normes : EN 60 335-2-37 CEI-61-63 55014 EN 60 555-2-3 The manufacturer deckares that the appliances are in compliance with the following Directions: 93/68 CEE 89/336 CEE 73/23 CEE.
- Page 5 SCHEMI ELETTRICI - ELECTRIC DIAGRAMS SCHEMAS ELECTRIQUES - SCHALTPLAN - ESQUEMAS ELECTRICOS Mod. GYROS 10 E Mod. GYROS 20 EIR Mod. GYROS 40 E / 70EIR Mod. GYROS 60 E / 90EIR Mod. GYROS 80 E Mod. GYROS 100 E - ER1÷6 - REGULATEUR D' - ER1÷6 - ENERGY - ER1÷6 - ENERGIEREGLER...
- Page 6 1. INSTALLATION 1.1 The installation, & the connection of the device must be done only by authorized technicians always according to the laws & ordinances, which are valid. 1.2 Remove carefully the plastic coverage from all parts of metallic surface of the device ahead & rear so as to be clear without plastic residues. For better cleaning use gasoline with oil or petrol.
