3. Safety advice

(1). Please read the entire instruction manual thoroughly before using the
child car seat . Improper installation can endanger the life of your child.
(2). Under no circumstances should the seat be installed on a passenger
seat equipped with an airbag. This can be very dangerous.
(3). It is most important that the seat belt is correctly routed.
(4). Never make unauthorized alterations or additions to the product.
(5). Never use the child car seat if it has been in an accident, or if it has
become badly worn.
(6). Do not leave your children in the seat unattended at any time.
(7). Child car seat parts may become hot in direct sunlight. Cover with a
sheet to prevent this.
(8). Make sure that your child never plays with the buckle as the buckle is
not fully tamperproof.
(9). Ensure that all other passengers, luggage and loose objects are
properly secured.
(10). Never use the child car seat without cover. Only covers approved by
manufacturer can be used.
(11). The child car seat must be secured with the car seat belt when not in
use.
(12). In an emergency your child can be released quickly by pressing the
red button on the seat belt buckle.
(13). Store this child car seat in a safe place when it is not being used. Avoid
placing heavy objects on it.
(14). Most accidents occur on short trips, so do not be tempted to avoid
using the seat simply because you are not travelling very far.
(15). Make sure to keep plastic bag long distance from your child as it is
likely to cause suffocation.
(16). Do not expose the child car seat to any corrosive substance. Use wet
towel to clean the plastic body instead of any solvent when the plastic
body is dirty.
(17). Make sure the child car seat belt is adjusted to suitable position and
the belt can't be twisted.
(18). It's very important to put any lap belt low down so that the pelvis is firmly
stressed.
(19). Do not use this product second hand as you never know its history.
4. Vehicle Application：
Not allowed to install child car seat.
Be careful to install child car seat. Installation is permitted only
!
if there is 3-point belt.The seat may not be installed in the area
of effect of an airbag.
Safe to install child car seat.ack into the metal yoke(O). (fig.5)
5. Components overview(fig.1)
A-Headrest J-Harness adjust strap
B-Backrest K-Seat base
C-Shoulder pads L-Diagonal belt routing slot for Group 0+
D-Innercushion M-Reclining board
E-Shoulder straps N-Shoulder strap slots
F-Harness buckle O-Metal yoke
G-Crotch pad P-Headrest adjusting lock
H-Harness adjust button
R-Headrest adjusting button
I-Red lever
6. Adjusting the belt system and headrest to the size of your
child
6.1 Adjusting the belt system
Make sure that the harness is on the same height as your child's shoulders.
Otherwise, move the shoulder strap up or down to the correct slot. (fig.2)
6.1.1 Undo the shoulder straps(E) out from the metal yoke(O). (fig.3)
6.1.2 Pull both the shoulder pads and shoulder straps out from the slot and
re-insert them into the slot that corresponds to the height of your child
shoulders. Ensure the straps are not twisted.(fig.4)
6.1.3 Put the 2 shoulder straps back into the metal yoke(O). (fig.5)
ENG
