Arthrex Synergy Resection Quick Start Manual

Synergy
Unpacking
Carefully unpack and inspect all components for shipping damage. Save the packaging for later transport of
the device.
The Synergy Wireless Footswitch user's manual, shaver handpiece, Synergy
Resection
CoolCut™ shaver and burr DFU should be read prior to using these devices. The user manual and DFU provide
the indications and contraindications for use, warnings, symbol definitions, and the full list of product
instructions. These documents can be found on Arthrex.com.
Setup
1
Power ON console. Fully connect receiver...
3
Insert 2 AA alkaline batteries into the footswitch,
(+ side first, so that the - side is facing the end cap).
Then screw on the compartment cover end cap.
5
Battery indicator light will When the red flashing light disappears, the
rapidly flash red during footswitch is paired. Note: The footswitch must
pairing phase (can take be laid flat on the ground to function. If pairing is
up to 11 seconds). unsuccessful, repeat the previous steps and ensure
that the batteries have sufficient power.
Resection™
2 2a
...to footswitch port on
console.
4
Pairing button - Pair footswitch by simultaneously pressing the receiver and footswitch
pairing buttons, then release (footswitch must be within 6 feet of the receiver during
this process). Note: The footswitch must be held vertically so that the handle is fac-
ing the ceiling when pressing the pairing button.
6
Wireless Footswitch
2b
Placement is shown above.
4a

Quick Start Guide

Console, and each
Resection
