500
FE185C057HA-1
1:1.4/1.8mm 2/3" C-Mount
Before using this product, please read this operation manual carefully,
and keep the manual handy for future use.
/ FOR YOUR SAFETY USE
/ FOR YOUR SAFETY USE
This content explains important notices for all the users to use this product safely. Read the content carefully
before using, and follow the instructions.
The following signs of
WARNING and
WARNING Indicates the possibility of causing death or serious injury when misused.
CAUTION
Indicates the possibility of causing injury or substantial damage when misused.
WARNING
Do not look at any sorts of strong illuminant such as the sun through the lens. Eyes could be harmed.
CAUTION
Do not leave or store the lens under direct sunshine. The lens may condense light on a near-by object, and
cause a fire.
Do not remodel the instrument without permission: it may impair the functions of product. Please
contact our sales agent or Fujinon service department if remodeling is necessary.
NOTICES
Lens and its accessories are extremely precise instrument, then be sure not to apply the strong impacts to
them.
There may be a case that the glasses of the lens mist when the lens is carried from a cool place to a place of
high temperature and high humidity. To avoid a mist on the glasses, before moving the lens, let the lens
adjust to the ambient temperature of the place where the lens will be used.
For safe storage of the lens, avoid hot or humid place, and avoid places containing corrosive gas or salt.
Put the cap on the lens while the camera is not used for a long time.
/ GENERAL DESCRIPTION
This lens is a fish-eye lens developed for mega-pixel cameras with 5-mega-pixel CCD. It can be used for
FA
various applications such as surveillance and factory automation.
/ OUTLINE DRAWING
/ MOUNTING THE LENS
Press the threaded portion of the lens mount against the threaded portion of the camera mount, slowly rotate
the lens clockwise, and screw in the lens mount to be installed on the camera.
CAUTION show:
202B10908233
LC10A-1 1708
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FUJINON FE185C057HA-1
Summary of Contents for FUJINON FE185C057HA-1
- Page 1 Do not remodel the instrument without permission: it may impair the functions of product. Please contact our sales agent or Fujinon service department if remodeling is necessary. NOTICES Lens and its accessories are extremely precise instrument, then be sure not to apply the strong impacts to them.
- Page 2 / IRIS OPERATION 1) Loosen the iris locking knob. 2) Rotate the iris ring of the lens. For “open,” rotate it clockwise, as viewed from the camera side. 3) Tighten the iris locking knob. / OPTICAL & MECHANICAL SPECIFICATIONS / ENVIRONMENTAL CONDITIONS / MAINTENANCE OF THE LENS A special coating has been applied on the lens surface in order to prevent light reflection.
