Page 1: Quick Start Guide
Programmable Power Technology Quick Start Guide XRP7714EVB-DEMO-2-KIT XRP7714EVB-DEMO-2P-KIT... - Page 2 A ttach the Boards Orient the Exar Communications Module (XCM) and the Demo Board as shown. Align the pins of the 10 pin headers. Press the boards together to mate the XCM to the Demo Board.
- Page 3 The board should have been recognized already, if not, go to the File Menu and perform a “Board Search” to locate the board. The evaluation board manual may also be downloaded from www.exar.com/PowerXR.
- Page 4 E X a R C O R P O R aT I O n 48720 Kato Road Fremont, CA 94538 T. +1.510.668.7000 U.S.A. F. +1.510.668.7001 E x A R i S A T R A d E m A R K o F E x A R C o R p o R AT i o n . A l l oT h E R T R A d E m A R K S A n d R E g i S T E R E d T R A d E m A R K S A R E p R o p E R T y o F T h E i R R E S p E C T i v E o w n E R S .
