GENERAL DESCRIPTION
The EXAR XRP76XX Evaluation kit is a fully
assembled and tested surface-mount PCB that
demonstrates
the
XRP7674
and
XRP7675
regulators.
The
regulator generates a preset 3.3V output with
a load of up to 2A (XRP7664, XRP7674) and
3A (XRP7665, XRP7675).
The EVB kit requires a single input voltage VIN
source if EN is tied to VIN via jumper J1
(default setting as supplied from EXAR). If J1
is set to EN=EXT position then a logic-level
signal is required at EN pin in order to turn the
regulator on and off.
STANDARD CONFIGURATION
The
XRP76XXEVB
configured to operate under the following
conditions and parameters:
• Input voltage range:
• Output voltage range:
• Output current/load range:
EVALUATION BOARD SCHEMATICS
VIN
C2
DNP
GND
Exar Corporation
48720 Kato Road, Fremont CA 94538, USA
2A/3A 18V Synchronous Step-Down Regulator, Constant frequency
XRP7664,
XRP7665,
synchronous buck
current-mode
switching
evaluation
board
4.5V - 18V
0 – 2A/3A
J1
EN=VIN
R4 100k
U1
CBS
10nF
XRP76XX
1
BS
SS
2
IN
EN
3
SW
COMP
SW
4
C1
GND
FB
uF
Fig. 1: XRP76XX Evaluation Board Schematics
(XRP7664-65), Light-Load efficiency (XRP7674-75)
EVALUATION BOARD MANUAL
FEATURES
• 2A/3A Continuous Output Current
• 4.5V to 18V Wide Input Voltage
• PWM Current-Mode Control
is
• Adjustable Output Voltage
− 2% Accuracy
• Programmable Soft-Start and Enable
Function
3.3V
• Constant frequency (XRP7664-65)
• Light-load efficiency (XRP7674-75)
• Built-in Thermal, Over Current, UVLO
and Output Over-Voltage Protections
• RoHS Compliant "Green"/Halogen Free
8-Pin Exposed Pad SOIC Package
EN=EXT
EN
1
CSS
0.1uF
8
7
L1
SW
6
CC1
CC
uH
5
DNP
nF
FB
RC
k
Tel. +1 510 668-7000 – Fax. +1 510 668-7001
XRP7664-65-74-75
SW
1
VOUT
R1
26.1k
C3
C4
FB
22uF
22uF
R2
10k
GND
Rev. 2.0.0
www.exar.com
