Clas Ohlson SMP-600A-1 Manual

USB Mains Adaptor
Art.no 18-2697 Model SMP-600A-1-UK
36-4862
Please read the entire instruction manual before using the product and save it for future reference.
We reserve the right for any errors in text or images and any necessary changes made to technical data.
If you have any questions regarding technical problems please contact our Customer Services.
Safety
• This adaptor should only be repaired by qualified
service technicians.
• The adaptor should not be taken apart or modified.
• Do not place the adaptor where there is a risk of it
falling into water or other liquid.
• Do not subject the adaptor to impacts or vibrations.
• Do not short circuit the adaptor's output socket.
• Do not connect devices that use more than 2.1 A.
• Disconnect the adaptor from the mains when it is not
in use.
• Make sure that the load device is turned off before
connecting it to the adaptor.
Warning:
• Incorrect voltage or polarity can cause damage to
connected devices.
• Turn off the connected device before connecting/
disconnecting the adaptor.
• Always check the polarity with a multimeter or similar
instrument if you are in the least unsure.

Product description

Mains adaptor suitable for devices normally powered or
charged via a USB port, max load 2.1 A. Comes with nine
interchangeable connectors for, amongst other things,
Micro USB type B (Smart Phones/Android phones),
Mini USB, connectors for older phone models by Nokia,
Samsung and Sony Ericsson. The mains adaptor can
be used to charge iPod/iPad/iPhone if the original cable
is used. Energy saving adaptor with auto shut-off which
completely turns off the adaptor and draws no current if
no device is connected.
Contents
• AC/DC mains adaptor
• USB cable
• 9 DC connectors for various devices.
GREAT BRITAIN • CUSTOMER SERVICE
tel: 0845 300 9799 internet: www.clasohlson.com/uk
e-mail customerservice@clasohlson.co.uk
SMP-600A-1
Operation
1.
2.
3.
4.
5.
6.
7.

Care and maintenance

Unplug the adaptor before cleaning it. Clean the adaptor
using a soft, moist cloth and never use strong detergents or
solvents.
Disposal
This product should be disposed of in accordance with
local regulations. If you are unsure how to proceed,
contact your local authority.

Specifications

Rated voltage
Cable length
Make sure that the current used by the connected
device does not exceed 2.1 A.
Connect the USB cable to the adaptor.
Find out which of the adaptor's DC connectors fits
your product (try the connectors for size while they
are still loose). Join the DC charger connector to the
adaptor's cable connector by pushing them together.
Make sure that the DC connector and the cable
connector are securely pushed together.
Connect the DC connector to the load device.
Make sure that the load device is turned off before
connecting the DC connector.
Connect the adaptor to the mains, the LED should
light up.
Turn the load device on.
Input: 100–240 V AC, 50/60 Hz
Output: 5 V DC, 2.1 A
0.6 m
