- Page 1 YOUR WEIGHING SOLUTIONS Basic Terminal 3010 Operating Manual www.soehnle-professional.com...
-
Page 2: Table Of Contents
English Contents Introduction ........... ..Page 3 Operating manual notes . -
Page 3: Introduction
English Thank you for choosing this Soehnle Professional product. All the features of this product were designed to the state of the art and are optimised for simple and straightforward use. If you have any queries or experience any problems with the appliance that are not addressed in the operating instructions, please contact your Soehnle Professional service partner or visit us on the web at www.soehnle-professional.com. -
Page 4: Putting Into Operation
English Putting into operation Before connecting the power plug to the mains, make sure that the power supply specified on the nameplate and the power plug version comply with local conditions. Place the connected scales on a level and stable surface. Protect the application by selecting a site of installation that is not subject to shocks, vibration, intensive heat or cold, draughts, chemicals or moi- sture. -
Page 5: Symbols
English Symbols Active measuring point (scale) Active weighing range Zero reading Net weighing Tare reading Manual tare Hold mode (The reading is fixed to improve legibility) Total memory Piece count mode Alibi memory O1-O4 Switching points (Outputs O1 - O4) Description of the nameplate Weighing ranges Maximum load of weighing range... -
Page 6: Control Keys
English Control keys Operating mode Setpoint input Setting mode On / Off One menu level back, Zeroing key or Clear or shift an editable decade Set input to zero from right to left tare Next setting step or Tare key Increment value increment value Next setting step or... -
Page 7: Electronic Nameplate
English Electronic nameplate Press the Info key twice to display the electronic nameplate. Press the arrow keys ( ) to indicate the electronic nameplate, the Serial No. and the calibration counter of the activated measuring points in the display. Press the CL key to cancel or end display of the electronic nameplate. With a 1 or 2-range scale, the parameters of the other ranges disappear. -
Page 8: Basic Functions
English Basic functions The basic functions are similar or identical for all application programs. Power-on Only when the scale is not loaded. After the test routine, the display is set to zero. The scale is ready for use. Place the weighing product on the scale. The display shows the gross weight. -
Page 9: Taring Function
English Taring function Manual tare Place an empty container on the platform and press the -key. Manual tare input In Setting mode (see separate description 470.702.078 User Mode), select "Manual tare input" to assign the key. Then in operation, press the -key to set the value using the arrow keys The set value is accepted by pressing the -key. -
Page 10: Ten Times Resolution X10
On non-approved scales, the high resolution appears as long as you press -key and the Zeroing key. Switching over the scales (measuring points) The Basic Terminal 3010 can operate 2 analogue measuring points. Toggle between the measuring points by pressing the INFO key followed by -key (in succession). -
Page 11: Hold Function
English The selected data record is displayed in scroll mode as follows: Display Meaning Consecutive number of alibi entry 2880 Scale type Serial number of mea- Year suring point 000I Consecutive number A I2,34 Gross or net with alibi ID A 2,98 Tare with alibi ID Scroll by pressing the arrow keys (... -
Page 12: Measuring Point Inputs And Outputs
English 2.10 Inputs and outputs The optional I/O module has 4 inputs and outputs that can be individually configured in Setting mode (see (separate description 470.702.078 User Mode). 2.11 LED lamps The appliance has integrated LED lamps. The functionality can be set and activated individually for each application program in Setting mode (see separate description 470.702.078 User Mode). -
Page 13: Application Programs
English Application programs The various application programs on the Soehnle Basic Terminal 3010 offer you a wide range of solutions for weighing operations. You can modify the application programs to your specific requirements in Setting mode (see separate description 470.702.078 User Mode). -
Page 14: Totalising
English Displaying the piece weight Press the Info key and then the counting key to display the piece weight. Press the CL key to go back. 3.3 Totalising Place weighing product on the platform in Weighing mode and accept the weight value in the total memory by pressing the + key. -
Page 15: Batching
English 3.4 Batching Place weighing product on the platform in Weighing mode and accept the weight value in the batch memory by pressing the + key. Place the next weighing product on the platform and press the + key to accept the weight value in the batch memory, etc. -
Page 16: Switching Point Programming
English 3.6 Switching point programming Four switching points can be set in the Basic Terminal 3010. The switching points are used for switching and dosing. Setting the switching points Press the switching point key. The first switching point is displayed. This is indicated by the arrow in the display. - Page 17 English Select the dosing function in Setting mode (see separate description 470.702.078 User Mode and 470.051.109 Dosing). Use the switching points (see 3.6) to set coarse flow, fine flow and correction value. Setting the switching points S1 Setpoint for coarse dosing S2 Setpoint for fine dosing S3 Correction value for coarse dosing S4 Correction value for fine dosing...
-
Page 18: Troubleshooting
English Troubleshooting Display Remedy Please check that you operated the appliance correctly. If not, interrupt the command chain by pressing the CL key. The scale sets the value zero auto- Clip off the platform. Possibly remove matically when it is switched on. If any soiling. - Page 19 English 1 1 9 9...
