eView HD
OPERATING INSTRUCTIONS MANUAL
codice: 80587_ 02-2019 - ENG
ATTENTION!
This manual must always be available to operators of the
devices described here.
Always make sure that you have the latest version of the
manual, which is available for free download from the GEFRAN
website (www.gefran.com).
Installers and/or maintenance personnel are required to read
this manual and to precisely follow the instructions contained
in it and in its attachments.
GEFRAN will not be liable for any damage to persons and/or
property, or to the product itself, caused by failure to follow
the instructions and observe the warnings given below.
This manual and its attachments may be freely reproduced
as long as they are not changed in any way and every copy
contains this warning and the declaration of ownership by
Gefran S.p.A.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for gefran eView HD 101
Summary of Contents for gefran eView HD 101
- Page 1 GEFRAN will not be liable for any damage to persons and/or property, or to the product itself, caused by failure to follow the instructions and observe the warnings given below.
- Page 2 CODE UPDATE N. pages of the document Copyright © 2018 Gefran Soluzioni Subject to change without notice The information contained in this document is provided for informational purposes only. While efforts were made to verify the accuracy of the information contained in this documentation, it is provided “as is” without warranty of any kind.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. PRODUCT OVERVIEW ........... 5 2. STANDARDS AND APPROVALS ........5 3. TECHNICAL SPECIFICATIONS ........7 4. TECHNICAL DATA ............8 4.1. Dimensions ..............9 4.2. Installation Environment ......... 10 4.3. Safety instruction ............ 10 4.4. Installation Procedure ..........10 5. - Page 4 The operational guidelines described below is information This Operating Instruction describes the main features of the which relates to the device, installation, transportation, Gefran Soluzioni srl operator panels. The Manual refers to the storage, assembly, use and maintenance. following models: eView HD 070 Operator interface with TFT color 7”...
-
Page 5: Product Overview
IoT edge applications in factory, marine and • Gateway function with OPC UA Server and Client. building automation. • Secure connectivity with Gefran Cloud and full network The glass projected capacitive touchscreen and the brilliant separation. displays with size up to 21.5” and resolution up to 1920x1080 •... - Page 6 An example of this plate is shown in the figure below: Note: the eView HD label is used as an example for eView HD Series MADE IN ITALY Gefran Soluzioni srl This product contains a battery. Dispose of the Via Sebina, 74 battery according 25050 Provaglio d’Iseo (BS) - ITALY...
-
Page 7: Technical Specifications
Serial Port RS-232, RS-485, RS-422 software configurable Flash 4GB for eView HD 070, eView HD 101, 8GB for eView HD 156, eView HD 215 1GB for eView HD 070, eView HD 101, 2GB for eView HD 156, eView HD 215... -
Page 8: Technical Data
4. TECHNICAL DATA Model eView HD 070 eView HD 101 eView HD 156 eView HD 215 Display / Backlight TFT Color / LED Colors Resolution 800X480 1280X800 1366X768 1920X1080 Diagonal (inches) 7” widescreen 10.1” widescreen 15.6” widescreen 21.5” widescreen Dimming... -
Page 9: Dimensions
4.1. Dimensions Cut out MODEL eView HD 070 187mm/7.36” 147mm/5.79” 176mm/6.90” 136mm/5.35” 47mm/1.85” 8mm/0.31” eView HD 101 282mm/11.10” 197mm/7.80” 271mm/10.67” 186mm/7.32” 56mm/2.20” 8mm/0.31” eView HD 156 422mm/16.60” 267mm/10.50” 411mm/16.18” 256mm/10.00” 56mm/2.20” 8mm/0.31” eView HD 215 552mm/21.73” 347mm/13.66” 541mm/21.30” 336mm/13.22” 56mm/2.20”... -
Page 10: Installation Environment
4.2. Installation Environment • the borders of the cutout must be flat Avoid prolonged exposition to direct sunlight to avoid the risk • screw up each fixing screw until the bezel corner get in of overheating the device. contact with the panel. The equipment is not intended for installation in contact with •... -
Page 11: Connections
5. CONNECTIONS eView HD 070 eView HD 101 eView HD 156 eView HD 215 1. USB Port V2.0, max. 500 mA - for maintenance only 5. Ethernet port 0 (10/100/1000Mb) 2. Ethernet port 2 (10/100Mb) 6. Power Supply 3. Ethernet port 1 (10/100Mb) 7. -
Page 12: Ethernet Port
5.2. Ethernet Port The Ethernet port have two status indicators. Please see description in figure. Yellow Green OFF: Valid link has NOT been detected ON: No activity ON: Valid link has been detected BLINKING: Activity 5.3. Optional plugin module eView HD panels have several optional plugin module, multiple modules configurations are possible.. Slot#2 and Slot#4 are available only if plugin module has the “bus extension connector”. -
Page 13: Optional Plugin Module Installation Procedure
5.4. Optional plugin module installation procedure 80587_eView HD_02-2019_ENG... -
Page 14: Power Supply, Grounding And Shielding
6. POWER SUPPL Y , GROUNDING AND SHIELDING The power supply terminal block is shown in the figure below. Figure 6.1 3 conductor 1,5mmq wire size minimum, minimum temperature conductor rating 105°C. Note: The power supply circuit may be floating or grounded. In the Ensure that the power supply has enough power capacity for the operation of the equipment. -
Page 15: Battery
When the battery is fully charged, it ensures a period of 3 • hardware real-time clock (date and time) months of data back-up at 25°C. Battery Figure 7.1: eView HD 070, eView HD 101, eView HD 156, eView HD 215 ATTENTION ATTENTION Dispose of batteries according to local This device cannot be disposed of as regulations. -
Page 16: System Settings
10. SYSTEM SETTINGS eX Series 700 HMI products have a system settings interface enter the address https:// IP/machine_config where IP is the to allow configuration of system options. IP address of the HMI device. Default username is “admin”, The user interface of System Settings is based on HTML default password is “admin”. - Page 17 Note: Additional informations on System Settings are Services Enable/disable services. Examples of available in dedicated manual services are: OpenSSH server, Bridge, https://www.gefran.com/gefrancloud/. Cloud, Router, SNMP and logging. Management Update of BSP components (Main OS, Config OS, Boot loader, XLoader), check for partitions consistence, update of splash screen, information about usage and size of partitions.
-
Page 18: Unpacking And Packing Instructions
11. UNPACKING AND PACKING INSTRUCTIONS Figure 11.1: eView HD 070, eView HD 101 Figure 11.2: eView HD 156, eView HD 215 To repack the unit, please follow the instructions backwards. 80587_eView HD_02-2019_ENG... - Page 19 NOTE 80587_eView HD_02-2019_ENG...
- Page 20 Gefran Soluzioni srl Via Sebina 74 - 25050 Provaglio d’Iseo (BS) Italy Tel. +39 0309888.1 - Fax +39 0309839063 - info@gefran.com http://www.gefran.com www.gefran.com/en/gefran-soluzioni...
