Eureka MAGNUM HDK User Manual page 41

DIRVE SYSTEM
Hydraulic traction on rear wheel.
FORWARD PUMP:
BONDIOLI PAVESI, piston pump with variable capacity NT12 20cm
(foot pedal control);
TRACTION ENGINE
EATON series 4000 of 310cm
SERVICE PUMP (FAN, MAIN BRUSH, HOPPER)
MZ pump with 6.4 cm
MAIN BRUSH ENGINE
Hydraulic engine EATON type T of 49 cm
VACUUM FAN ENGINE
Hydraulic engine MZ with gears of 4.5 cm
HYDRAULIC OIL FILTER
ARGO filter of 80 liters
Filtering capacity: 15 microns
Particle capture capacity: 25 gr.
HYDRAULIC OIL
Oil type: MOBIL HYDRO HV 46;
Tank capacity: 20 lt.
Total contents of the whole hydraulic plant including the tank: 25 lt.
Oil circulation: 36 liter/min
MOTOR REDUCER FOR SIDE BRUSH
Motor reducer for side brush dx: AMER AOMPI 40; Code: 6910247 (EUREKA CODE 610026)
License data: V12, G. 100, W 200 (KW 0.2)
Working absorption: A/h 12/15
KUBOTS DIESEL ENGINE
Model: D 902 three cylinders
Max continues power: kw 15.2 – HP 20.6 (3200 ROUNDS) DIN 6271 NB
N° of rounds (eureka calibration): RPM 2950/3000 free spins
Electrical starter 12V - 1400W
Battery starter 12V - 74A
Alternator 12V - 40A
Fuel tank capacity: lt. 15 + lt. 2.3 reserve
Fuel consumption 3000 RPM: from 2 Lt/h to 2.5 Lt./h
Working autonomy with full tank: from 8 to 6 + 1 hour reserve
Fuel level indicator
Water cooling 50% + 50%
Radiator liquid capacity + engine 3.8 lt.
Oil type: SAE 10 W 40 SUPERDIESEL
Oil quantity 3.7 lt
NOISE LEVEL ACCORDING TO LAW ISO 3744
Acoustic pressure medium level Lpm= 85 dB
Acoustic power level Lwa= 102 dB
Guaranteed acoustic power level Lwa,g = 106 dB
Acoustic pressure level (from operator's ear ): 84 dB
VIBRATIONS
The level of vibration to which the operator is subjected is below the maximum level allowed by the CE
DIRECTORY for industrial machinery ( CEE 89\392 ).
42
CHARACTERISTICS
3
;
3
gear;
3
;
3
;
3
with hydraulic servo control
