1. TOW HOOK
PROCEDURE FOR MOVING WITHOUT ENGINE OR DUE TO A PRESENCE OF A DAMAGE.
Insert the service brake
Open the seat hood
Turn red unlock pump lever, in an anti-clockwise way, until you reach position B
Close hood
Mount on machine and unlock service brake. The sweeper can now be moved maintaining the control of the driving
brake.
After having moved the sweeper, bring back lever to position A, pushing with force towards the end of its course.
PROCEDURE FOR TOWING THE MACHINE
Unlock pump as described above
Tow machine, using the tow hook pos.1 situated in the front left of the sweeper.
ATTENTION: DO NOT EXEED 2KM\H DURING THE PROCESS OF TOWING THE SWEEPER.
Exceeding this speed limit twill cause cavitations on motor and as well on piston pump.
Once the operation is finished, bring back red lever to position A, pushing with force towards it end of course.
