Summary of Contents for Edison Mini-triton+HD
- Page 8 SCART...
- Page 9 SPDIF...
-
Page 23: Table Of Contents
Contents Contents GENERAL INFORMATION Main Features For your Safety Unpacking General Operation INSTALLATION INSTALLATION GUIDE MAIN MENU 1. Program 2. Picture 3. Channel Search 4. Time 5. Option 6. System 7. USB 8. Hot key TROUBLE SHOOTING... - Page 24 GENERAL INFORMATION GENERAL INFORMATION This Digital Terrestrial Receiver (DTR) will take you to the new and exciting world of Digital Television. A world of crystal clear widescreen pictures, digital sound, more information and new services. All this and more on "Free to Air" Digital Television. To make full use of your new DTR please take the time to familiarize yourself with the extensive features of the unit detailed in this User's Guide.
- Page 25 GENERAL INFORMATION GENERAL INFORMATION For Your Safety To avoid electric-shock hazards, do not Keep the receiver away from flower vases, open the cabinet, refer servicing to qualified tubs, sinks, etc., in order to avoid damaging personnel only. the equipment. Do not expose the receiver un-der the Do not block ventilation holes of the sunlight.
- Page 26 GENERAL INFORMATION GENERAL INFORMATION Unpacking(optional) Remote Control Batteries User’s manual General Operation Throughout this manual you will notice that the everyday operation of the receiver is based on a series of user friendly on screen display and menus. These menus will help you get the most from your receiver, guiding you through installation, channel organizing, viewing and many other functions.
- Page 27 GENERAL INFORMATION GENERAL INFORMATION Function Turns power ON/OFF When watching a channel, mute the sound Enter number of the required menu item or select a channel number to watch TV/RADIO Switches between TV and Radio mode Switches back to previous channel Displays the favorite group list Timeshift function key SHIFT...
- Page 28 INSTALLATION INSTALLATION Rear Panel CONNECT TO DIGITAL AMPLIFIER POWER CABLE CONNECT TO TV USING A SCART CABLE CONNECT TO TV SET HDMI-OUT INPUT CONNECT TO USB DEVICE ANT IN: CONNECT TO ANTENNA LOOP: CONNECT TO ANOTHER RECEIVER Connecting to TV using SCART support Antenna SCART The picture is only for reference, please make the object as the standard.
- Page 29 INSTALLATION INSTALLATION Connecting to Digital Amplifier Antenna DIGITAL AUDIO CONVERTOR OR SPDIF AMPLIFIER SPEAKER The picture is only for reference, please make the object as the standard.
- Page 30 INSTALLATION GUIDE INSTALLATION GUIDE When power on first time, it will show Installation Guide like below. Press PR+,PR- keys to move highlight to select OSD language, Country and Channel Search. Press keys to move the cursor to choose your choice. Move highlight to Channel Search option and press OK key to search channels .
-
Page 31: Main Menu
MAIN MENU MAIN MENU When you press [MENU] key, you can enter Main Menu. This menu consists of 7 major sub-menus as follow. - Program - Picture - Channel Search - Time - Option - System - USB 1. Program This menu consists of 4 major sub-menus as follow. - Page 32 MAIN MENU MAIN MENU 4. Select the program and press green key to mark this program with the skip mark. You can cancel this mark by pressing green key once more. 5. Select the program and press blue key to pop up a warning dialogue:"...
- Page 33 MAIN MENU MAIN MENU 2. Picture This menu consists of 4 major sub-menus as follow. - Aspect Ratio - Resolution - TV Format - Video Output 2.1 Aspect Ratio Select among 16:9 Pillar Box, 16:9 Pan&Scan, 4:3 Letter Box, 4:3 Pan&Scan, 4:3 Full, 16:9 Wide Screen and Auto.
- Page 34 MAIN MENU MAIN MENU 3.2 Manual Search Frequency channel: Press key to select the channel Frequency: Press number key to input. Bandwidth: Press keys to select among 6,7 and 8M Through two colour dynamic bars at the bottom of the search window, users can know signal quality and strength of current therefore channel.
- Page 35 MAIN MENU MAIN MENU 5. Option There are 5 sub-menus in this menu - OSD Language - Subtitle Language Audio Language - Digital Audio - Audio Description 5.1 OSD Language Press keys to select the language in circle. 5.2 Subtitle Language Press keys to select the language in circle.
- Page 36 MAIN MENU MAIN MENU 6.2 Set Password Input old pass word: Input the pass word by pressing number keys 0-9. Input new pass word: Input the pass word by pressing number keys 0-9. Confirm new pass word: Press number key 0-9 to input new pass word again.
- Page 37 MAIN MENU MAIN MENU 7. USB This menu has 4 sub-menus such as: Multimedia, Photo Configure, Movie Configure, PVR Configure and Record. 7. 1 Multimedia There are 4 sub-menus in this menu - Music - Photo - Movie - PVR These menus will be disabled when no USB device is plugged.
- Page 38 MAIN MENU MAIN MENU In PVR menu you can see the program you recorded. Press red key to switch to full screen mode, and press exit key to back to preview mode. Press yellow key to delete the program. Press green key to rename the program. Press OK or key to play the program.
-
Page 39: Hot Key
MAIN MENU MAIN MENU 8. Hot Key 8.1 Number Use the numeric keys (0-9) to input the number of the desired channel. If the inputted number is beyond the valid channel number, system will "Invalid number” and press OK key to close this message. 8.2 TV/RADIO In normal mode, press TV/RADIO key to switch between TV mode and Radio mode. - Page 40 MAIN MENU MAIN MENU 8.9 Audio 1. Press AUDIO key to enter into the Audio window. 2. Press keys to select between Left-Left, Right-Right and Left-Right. 3. Changing the audio mode is only connected with the current channel, not all the channels. 4.
-
Page 41: Trouble Shooting
TROUBLE SHOOTING TROUBLE SHOOTING Problem Possible causes What to do The display on the front Check that the main cable is plugged into Main cable is not connected. panel does not light up. the power socket. No sound or picture, but the receiver is in standby mode.
