Artisan
ITEMS PROVIDED IN THIS KIT MODEL ART-ISB:
Infrared Sear Burner
INSTALLATION:
WARNING:
Disconnect 110V AC power to the grill before servicing the unit.
(Applies to 32" and 36" units only).
The Infrared Sear Burner for your Artisan™ USA Grill
can be used in any existing grill burner location you
prefer: left, center or right.
Remove the grill grate and briquette tray from
•
the desired location as shown on the right .
(See Figure 1).
Lift and remove the U-BURNER out of the grill.
•
The U-BURNER is simply resting between the
gas valve and the rear bracket located in the
back wall. (See Figure 2)
USA
™
INFRARED SEAR BURNER
Sear Burner Electrode
GRATE
BRIQUETTE
TRAY
U-BURNER
Figure 1
Figure 2
1
Advertisement
Table of Contents
Related Manuals for artisan ART-ISB
Summary of Contents for artisan ART-ISB
- Page 1 Disconnect 110V AC power to the grill before servicing the unit. (Applies to 32” and 36” units only). The Infrared Sear Burner for your Artisan™ USA Grill can be used in any existing grill burner location you prefer: left, center or right.
- Page 2 Using a screwdriver, remove the electrode screw • and pull the U-BURNER electrode out SLOWLY. SCREW There is additional ignition wire located inside the front of the grill in order to pull the connector approximately 1” outside of the front wall. (See Figure 3) Remove the electrical wire connected to the •...
- Page 3 To adjust the gas valve LOW setting, please refer to the grill’s care and use manual. • Artisan ™ USA Grills • 1085 Bixby Drive • City of Industry, CA 91745 • 888-383-8800 • 323-722-7900 • Fax 323-726-4700...
