Summary of Contents for artisan ARTC-SBM
- Page 2 ASSEMBLY PROCEDURE: STEP 1: EXISTING SHELF To begin installing the Side Burner Mounting Shelf in Artisan your cart, you must first remove the appropriate existing shelf unit out of it. This is accomplished by re- moving the 4 screws and...
- Page 3 NEW ARTC-SBM STEP 2: SHELF UNIT Install the ARTC-SBM shelf unit by using the same screws and washers you saved on STEP 1. Tighten screws while align- ing the shelf to the sides and top edges of the cart unit’s side panel.
- Page 4 STEP 4: Fasten the ART-SB1 Side GROMMET Burner to the ARTC-SBM side mounting shelf with the 4 screws and lock washers provided in this kit. (See figure # 4) Insert the grommet pro- vided to protect and guide the supply gas line to the side burner unit.
- Page 5 NOTES:...
- Page 6 Artisan ™ ARTC-SBM Assembly Instructions Artisan ™ USA Grills All Rights Reserved • 06/2011...
