- Page 1 Keysight N9038A MXE EMI Receiver External Mixing Upgrade Hardware plus Option HL6 Installation Note...
- Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 Prerequisites In addition to the serial number requirements mentioned above, there are other prerequisites that must be met before installing this Option HL6 upgrade in an N9038A MXE EMI Receiver. It is: Options: N9038A-W7X...
-
Page 4: Table Of Contents
Option HL6 – External Mixing Upgrade - Hardware Plus What you will find in this Document Information....................... page 5 Contents ........................... page 7 Tools Required ......................... page 8 Initial Instrument Functionality Check ................page 9 Instrument Operating System Requirement Verification .......... -
Page 5: Esd Information
Option HL6 – External Mixing Upgrade - Hardware Plus ESD Information Protection from Electrostatic Discharge Electrostatic discharge (ESD) can damage or destroy electronic components. All work on electronic assemblies should be performed at a static-safe workstation. Figure 1 shows an example of a static-safe workstation using two types of ESD protection: —... - Page 6 Option HL6 – External Mixing Upgrade - Hardware Plus Handling of Electronic Components and ESD The possibility of unseen damage caused by ESD is present whenever components are transported, stored, or used. The risk of ESD damage can be greatly reduced by paying close attention to how all components are handled.
-
Page 7: Contents
Option HL6 – External Mixing Upgrade - Hardware Plus Contents Reference Description Part Number Quantity Designator A1A1MP1 Overlay, Main Keyboard N9038-80001 Front End Assembly N9038-60314 Connector, Front Panel - External Mixing 1250-1666 8121-2027 Cable, Coaxial, Front End Assy (A13) J13 to Front End Ctrl (A15) J903 Cable, Semi-Rigid, Limiter Assy (A23) J103 to Coaxial Switch (SW1) Port 1 N9038-21301 Cable, Semi-Rigid, W46 to Front End Assy (A13) J8... -
Page 8: Tools Required
Option HL6 – External Mixing Upgrade - Hardware Plus Tools Required — Torx Driver T-10 — Torx Driver T-20 — 1/4” Open End Wrench — 5/16" Open End Torque Wrench — 3/8” Deep Socket Torque Wrench — Multi-Bit Torque Driver —... -
Page 9: Initial Instrument Functionality Check
System, Show, System and verify that there is an entry for: N9038A-W7X Windows Embedded Standard 7, 64 bit OS If N9038A-W7X is not found in the instrument do not proceed any further with this upgrade. Option N9038AK, N9094AK-PC6 (or greater) and N9094AK-W7X will need to be installed before proceeding. -
Page 10: Overview
Option HL6 – External Mixing Upgrade - Hardware Plus Overview Outer Hardware Removal 1. Referring to the MXE Service Guide Chapter 18, Assembly Replacement Procedures: a. Remove the Instrument Outer Case b. Remove the Top Brace c. Remove the Front Frame assembly Front End Assembly Replacement 2. - Page 11 Option HL6 – External Mixing Upgrade - Hardware Plus 3. Referring to Figure 3, remove the three 50 Ω terminations (2) from J3, J5, and J8. Two of these terminations will be reused. Figure 3 A13 Front End Assembly Removal 4.
- Page 12 Option HL6 – External Mixing Upgrade - Hardware Plus 11.Reconnect W38, W18, W44, W42, W16, and W40 to the A13 Front End assembly. Torque all connections to 10 inch-lbs. using a 5/16" open end wrench. 12.Replace a 50 Ω termination (2) onto J3 and J5. Torque them to 10 inch-lbs. using a 5/16" open end wrench.
- Page 13 Option HL6 – External Mixing Upgrade - Hardware Plus 15.Referring to Figure 5, carefully route the other end of the W24 cable across the top of the instrument to J903 of the A15 Front End Control assembly, making sure that it snaps in securely.
-
Page 14: Front Frame Assembly Modification
Option HL6 – External Mixing Upgrade - Hardware Plus Front Frame Assembly Modification 18.Referring to Figure 6, remove the RPG knob (1) from the face of the front frame assembly by firmly grasping it and pulling it straight off of its shaft. This knob will be reused. Figure 6 A1 Front Frame Assembly 19.Remove the main Keyboard overlay (2) by carefully prying it loose from the front frame... - Page 15 Option HL6 – External Mixing Upgrade - Hardware Plus 24.Referring to Figure 7, install the new J3 Front Panel Connector (1) using the new lock washer (2) and hex nut (3). Torque to 21 inch-lbs. using a 3/8" socket wrench. Figure 7 External Mixing Front Panel Connector Installation 25.Locate the new 50 Ω...
- Page 16 Option HL6 – External Mixing Upgrade - Hardware Plus 26.Referring to Figure 8, attach the new W46 cable to the back side of J3 but do not tighten it all the way. Figure 8 W46 Cable Installation Installation Note N9038-90040...
- Page 17 Option HL6 – External Mixing Upgrade - Hardware Plus 27.Referring to Figure 9, orient W46 so that the cable slopes upward from the J3 connector at a 15 degree angle. The top of the connector should be approximately level with the top of the shield over the front panel interface board.
-
Page 18: Front Frame Assembly Replacement
Option HL6 – External Mixing Upgrade - Hardware Plus Front Frame Assembly Replacement 28.Using a T-10 driver verify that all screws in the instrument that are accessible at this point are properly torqued to 9 inch-lbs. 29.Using a 5/16" open end wrench verify that all cables in the instrument that are accessible at this point are properly torqued to 10 inch-lbs. - Page 19 Option HL6 – External Mixing Upgrade - Hardware Plus 32.Referring to Figure 11, reattach the front frame assembly to the instrument chassis using the original 8 screws (1) and torque to 9 inch-lbs. using a T-10 driver (there are 4 screws on each side).
- Page 20 Option HL6 – External Mixing Upgrade - Hardware Plus 33.Referring to Figure 12, carefully attach the loose end of W46 to the loose end of W45. 34.Using a 1/4" open end wrench to keep W45 from rotating, torque the connector on W46 to 10 inch-lbs.
-
Page 21: Instrument Button Up
Option HL6 – External Mixing Upgrade - Hardware Plus Instrument Button Up 35.Referring to the MXE Service Guide Chapter 18, Assembly Replacement Procedures, reinstall the Top Brace. 36.Locate the new EXM Warning Label (N9030-80018) and attach it to the Top Brace as shown in Figure Figure 13 EXM Warning Label Placement... -
Page 22: License Key Retrieval And Installation
Option HL6 – External Mixing Upgrade - Hardware Plus License Key Retrieval and Installation 41.Follow the instructions on the enclosed License Entitlement Certificate to redeem the new external mixing license key for the instrument being upgraded. 42.Once the new license key has been redeemed follow the installation instructions that come with the license file to install it into the instrument. -
Page 23: Upgrade Installation Verification
49.Verify that the external mixing upgrade license key has been installed by pressing System, Show, System and make sure that the following option is present: N9038A-EXM External Mixing 50.The installation of Option EXM is now complete. Proceed to the Adjustments and Performance Verification section of this document. -
Page 24: Adjustments And Performance Verification
Manual Procedures Required None Automated Utilities Required None Automated Adjustments Required Automated Performance Verification Testing Required For assistance, contact your nearest Keysight Technologies Sales and Service Office. To find your local Keysight office access the following URL: http://www.keysight.com/find/assist Installation Note N9038-90040... - Page 25 This information is subject to change without notice. © Keysight Technologies 2016-2017 Edition 1, December 2016 N9038-90040 www.keysight.com...
