Keysight N9038A MXE EMI Receiver
Option LSN
LISN Control Upgrade
Notice: This document contains references to Agilent.
Please note that Agilent's Test and Measurement busi-
ness has become Keysight Technologies. For more in-
formation, go to www.keysight.com.
Installation Note
Part Number N9038-90019
Printed in USA August 2014

Advertisement

Table of Contents
loading

Summary of Contents for Keysight Technologies N9038A

  • Page 1 Option LSN LISN Control Upgrade Notice: This document contains references to Agilent. Please note that Agilent’s Test and Measurement busi- ness has become Keysight Technologies. For more in- formation, go to www.keysight.com. Installation Note Part Number N9038-90019 Printed in USA August 2014...
  • Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Keysight Technologies shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3: Installation Note N9038-90019

    Estimated Adjustment and Verification Time: 0 Hours This document provides detailed instructions for the installation of Option LSN - LISN Control board assembly in an N9038A MXE EMI Receiver. Please be sure to read this entire document before attempting to perform this upgrade. Contents...
  • Page 4: Table Of Contents

    LISN Control Upgrade What you will find in this document ESD Information ............page 5 Protection from Electrostatic Discharge .
  • Page 5: Esd Information

    LISN Control Upgrade ESD Information Protection from Electrostatic Discharge Electrostatic discharge (ESD) can damage or destroy electronic components. All work on electronic assemblies should be performed at a static-safe workstation. Figure 1 shows an example of a static-safe workstation using two types of ESD protection: ❏...
  • Page 6: Handling Of Electronic Components And Esd

    LISN Control Upgrade Handling of Electronic Components and ESD The possibility of unseen damage caused by ESD is present whenever components are transported, stored, or used. The risk of ESD damage can be greatly reduced by paying close attention to how all components are handled.
  • Page 7: Installation Instructions

    LISN Control Upgrade Installation Instructions Instrument Software Version Verification 1. Determine what version of instrument software is currently installed in the MXE being upgraded by pressing the following front panel keys: System Show System The software revision can be found on this screen as the: Instrument S/W Revision NOTE If the instrument software version is not A.13.00 or higher it will need to be...
  • Page 8: Top Brace And Power Supply Bracket Removal

    LISN Control Upgrade Figure 2 Instrument Dress Cover Removal Top Brace and Power Supply Bracket Removal 7. Refer to Figure 3. Using the T-10 driver remove the twelve pan head screws (3) (0515-0372) attaching the MP10 Top Brace (1) to the chassis, along the Wire Hold Down 1 as shown in Figure 8.
  • Page 9: Figure 3 - Top Brace And Power Supply Bracket Removal

    LISN Control Upgrade Figure 3 Top Brace and Power Supply Bracket Removal Figure 4 Wire Hold Downs Installation Note N9038-90019...
  • Page 10: Rear Panel Removal

    LISN Control Upgrade Rear Panel Removal 11. Refer to Figure 5. Using the 9/16” nut driver remove W21 External Reference Input Cable (2) from the instrument rear panel EXT REF IN port. 12. If it exists, using a 5/16” nut driver remove W22 AUX IF Output Cable (3) from the instrument rear panel AUX IF OUT port.
  • Page 11: Right Outer Chassis Side Removal

    LISN Control Upgrade Right Outer Chassis Side Removal 14. Refer to Figure 6. Using the T-10 driver remove the two flat head screws (3) (0515-1035) attaching the MP5 Right Outer Chassis Side (1) to the front frame assembly. NOTE The two flat head screws (0515-1035) used to attach the MP5 Right Outer Chassis Side to the front frame assembly are longer than the rest of the flat head screws removed during this upgrade.
  • Page 12: New Rear Panel Installation

    LISN Control Upgrade New Rear Panel Installation 16. Remove the clear protective film from the outer surface of the new MP6 Rear Panel. 17. Refer to Figure 5. Position the new MP6 Rear Panel (1) onto the rear of the instrument. If one exists, insert W22 AUX IF Output Cable (3) into the AUX IF OUT port on the new rear panel and hand tighten the fastener as the rear panel is positioned onto the instrument.
  • Page 13: Lisn Control Cable Installation

    LISN Control Upgrade LISN Control Cable Installation 23. Refer to Figure 8. Install the W9 LISN Control Ribbon Cable (2) between A30 J1 and the rear panel AUX I/O port. Figure 8 A30 LISN Cable Installation 24. Using the 3/16” nut driver attach the W9 LISN Control Ribbon Cable (2) to the rear panel with the two hex standoffs (3) (0380-1858) provided as shown in Figure 8.
  • Page 14: Right Outer Chassis Side Installation

    LISN Control Upgrade Right Outer Chassis Side Installation 26. Refer to Figure 9. Using the T-10 driver attach the MP5 Right Outer Chassis Side (1) to the instrument with the eleven pan head screws (2) (0515-0372) and the two flat head screws (3) (0515-1035).
  • Page 15: Instrument Dress Cover Installation

    39. On the instrument front panel press and verify that there is an entry for: System Show System N9038A-LSN LISN Hardware Support 40. Press System Show Hardware and verify that there is an entry for:...
  • Page 16: Adjustments And Performance Verification

    LISN Control Upgrade Adjustments and Performance Verification Adjustments and performance verification testing requires the use of the calibration software. The latest software information and downloads are available at: http://www.agilent.com/find/calibrationsoftware Adjustments Required None Performance Testing Recommended None For assistance, contact your nearest Agilent Technologies Sales and Service Office. To find your local Agilent office access the following URL: http://www.agilent.com/find/assist Installation Note...
