2.1.2
Shaver Blades, Bur Description
1
1. Cutting tip.
2. Shaver blade/bur hub- connects to the shaver handpiece.
3. Alignment key.
2.2
Assembly/Installation Instructions
2.2.1
Shaver Blade Installation and Removal
To insert a shaver blade or bur:
1. Align the key on the blade hub with one of the slots in the collet.
2. Completely push the hub into the collet to lock it into place.
3. Pull on the blade to ensure it is locked.
To remove the blade or bur:
1. Rotate and hold the collet in the "UNLOCK" direction.
2. Remove the blade.
11
3
2
