- Page 1 HAGERMAN T E C H N O L O G Y Cymbal 8 Watt Monoblock Amplifier...
-
Page 2: Copyrights And Trademarks
The instructions in this manual are a suggested guide only and no liability is assumed by Hagerman Technology LLC. Copyrights & Trademarks © Copyright Hagerman Technology LLC 2004. All rights reserved. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of Hagerman Technology LLC. -
Page 3: Before You Begin
Description Congratulations! You have just purchased one of the highest performance-per-dollar audiophile products available. The Cymbal monoblock amplifier is intended to bring high-end audio and construction quality into the hands of do-it-yourselfers. It is part of a line of vacuum tube products based on a common chassis and circuit board architecture. -
Page 4: Parts List
Cymbal Monoblock Kit Manual 2 Parts to Buy If you purchased factory assembled Cymbals, skip to Chapter 5. The kit does not need to be built as specified, part substitutions or upgrades can be made at your discretion. It is recommended you read this entire manual before starting. - Page 5 Cymbal Monoblock Kit Manual Component Qty DigiKey References 100uF 350V 493-1442-ND C3, C4, C9, C14 220uF 16V 493-1284-ND 100nF 50V EF1104-ND C6L, C6R 1uF 400V PF4105-ND C12, C13, C22, C23 470nF 400V PF4474-ND C7, C15 100nF 400V PF4104-ND 10nF 2kV...
- Page 6 Cymbal Monoblock Kit Manual Component Qty AES References Wire S-WS16 Binding Post S-H263 Socket, 8-pin P-ST8-193G Socket, 9-pin P-ST9-214G V2, V3, V4, V5, V6 Tranny, Power P-T370FX Tranny, Output P-T1615 Choke P-T158Q 5AR4 5AR4 Screw #10 P-H245 Nut #10 S-HHN1032...
-
Page 7: Circuit Board
Cymbal Monoblock Kit Manual 3 Assembly Chassis The instructions below refer specifically to the Lansing Instruments’ enclosure. Follow these step-by-step instructions to machine the chassis pieces. If you plan to use upgraded RCA jacks or other controls, some mounting holes will not be the same as those specified on the drill guides;... - Page 8 Cymbal Monoblock Kit Manual Install fuse holder. Install RCA jacks and ground lift switch. Install inductor using #6 screws and short nylon spacers. Install heat sink shields near RCA connectors and transformer wiring. These are used only for shielding purposes.
- Page 9 Cymbal Monoblock Kit Manual Integration If built properly, everything should fit together like a glove. The chassis anodization acts as an electrical insulator. Make sure to scrape down to bare metal under the chassis screws to insure complete Earthing of all panels.
- Page 10 Cymbal Monoblock Kit Manual Completed assembly (left channel).
-
Page 11: Testing & Installation
Square wave performance at 10kHz and 1kHz residual distortion. Connections The Cymbal connects to your audio system just like any other power amplifier. In some installations where the amplifiers are remoted from the signal source, you can use the ground lift switch S1 to disconnect signal ground from amplifier ground. The differential input stage has a common mode range of about +/-1Vdc, which helps to eliminate possible ground loop induced hum. -
Page 12: Specifications
Cymbal Monoblock Kit Manual 5 Specifications The following specifications are subject to change without notice. Item Specification Power 8W into 8 ohms (see graph) Gain 15dB (1.5Vrms for full output) Input Impedance 47k ohm Bandwidth (-3dB) 10Hz to 95kHz Distortion 0.18% @1kHz @ 1W... -
Page 13: Warranty And Service
Technology LLC will, at its option, repair or replace the product at no charge to you provided you return it during the warranty period, transportation charges prepaid to Hagerman Technology LLC. This warranty does not apply if the product has been damaged by negligence, accident, abuse or misuse or misapplication, has been damaged because it has been improperly connected to other equipment or has been modified without the express written permission of Hagerman Technology LLC.
