LAUNCH
①
OBD-16 diagnostic
connector
②
ECU communication
indicator
③
Power indicator
④
Bluetooth/USB
communication
indicator
⑤
Mini USB port

1.4 Technical Parameters

X-431 PRO3:
Operating system: Android 5.1
CPU: Quad-core 1.3GHz processor
Battery: 7000mAh rechargeable polymer lithium battery
Memory: 1GB
Storage capacity: 16GB
LCD: 10.1 inch
LCD resolution: 1280 x 800
Touch screen: Capacitive touch screen
Cameras: 5.0 mega pixels rear and 2.0 mega pixels front
Wi-Fi: Support 802.11a/b/g/h
Bluetooth: Supported
Working temperature: 0
Storage temperature: -20
Diagnostic Connector:
Working voltage: 9 ~18V
Average working current: About 35mA
Standby current: About 25mA
Working temperature: -20 to 55℃
Storage temperature: -30 to 70℃
Storage humidity: <80%
Working humidity: <60%
X-431 PRO3 User's Manual — General Operations
To connect on vehicle's OBD2 DLC.
It flashes when the connector is communicating
with the vehicle.
It lights up while the connector is plugged into
the vehicle's DLC.
It indicates Bluetooth mode if the connector
is energized and illuminates blue (default
mode).
It illuminates red when the connector is
connected to X-431 PRO3 via USB cable.
For connecting the USB cable to X-431 PRO3.
℃
~ 45℃
℃
~ 70℃
4
