Parts list

Please quote the part number when ordering equipment.
Part number Description
A-5191-0019 Window replacement kit comprising:
Window assembly complete with O-ring
Stainless steel socket cap head screw M3 × 14 mm long
Stainless steel socket cap head screw M3 × 5 mm long
Hexagon wrench 2.5 mm across flats
